BeagleBoard Rev. C4

BeagleBoard Rev. C4

TI OMAP3530 single-board computer

The OMAP3530 includes an ARM Cortex-A8 CPU (which can run Windows CE, Linux or Symbian), a TMS320C64x+ DSP for accelerated video and audio decoding The Beagle Board is a powerful single-board computer developed by Texas Instruments, featuring their OMAP3530 system on a chip. The board is supported by a large community and is designed with open-source development in mind.

The Beagle Board measures about 3x3" and has all the functionality of a basic computer. With its numerous expansion options, the Beagle Board can be used as the backbone for a large variety of projects. The OMAP3530 includes an ARM Cortex-A8 CPU (which can run Windows CE, Linux or Symbian), a HD-video capable TMS320C64x+ DSP for accelerated video and audio decoding, and an OpenGL ES 2.0 capable 2D/3D GPU. Video outputs can be provided by the on-board S-video or DVI-D (HDMI connector) outputs.

The board also includes an MMC+/SD/SDIO interface, USB 2.0, 3.5mm stereo audio in/out connectors, and RS-232 and JTAG connectors.

The board can consume up to 2W of power, which can be provided via USB or an external 5V source, via the on-board barrel jack. Because of the efficient power consumption, the board requires no additional cooling.

Features

• 720MHz superscalar ARM Cortex-A8 processor
• Over 1,200 Dhrystone MIPS
• Up to 10 million polygons per second graphics output
• HD-video capable C64x+ DSP core
• 256MB LPDDR RAM
• 256MB NAND Flash
• I2C, I2S, SPI, MMC/SD capabilities
• DVI-D and S-video video output
• JTAG
• SD/MMC+ socket
• 3.5mm stereo in/out
• USB 2.0 HS OTG
• RS-232 serial

Contents

• BeagleBoard Rev. C4
