MYD-AM3359 Development Board

• MYC-AM335X CPU Module as Controller Board
• 800MHz TI AM335X Series ARM Cortex-A8 Processors
• 512MB (2*256MB) DDR3 SDRAM, 512MB Nand Flash
• Serial ports, 4 x USB Host, OTG, 2 x Gigabit Ethernet, CAN, RS485, TF, Audio
• Supports HDMI and LCD Display
• Optional 4.3 or 7 inch LCD/TSP
• Supports for Linux 3.1.0, Android 2.3.4 and Windows Embedded Compact 7

The MYD-AM335X Development Board designed by MYIR is a high-performance ARM Evaluation Module (EVM) using the MYC-AM335X CPU module as the core controller board. It is based on 800MHz Texas Instruments (TI) Sitara AM335x family of ARM Cortex-A8 Microprocessors (MPUs) that deliver high DMIPs at a low cost while also delivering optional 3D graphics acceleration and key peripherals. These TI Cortex-A8 MPUs include industrial interface options, such as EtherCAT and PROFIBUS, and can support the Linux, Android and Windows CE high-level operating systems. The combination of graphics and connectivity support makes TI AM335x MPUs ideal for home automation, industrial automation, enterprise/educational tablets, portable navigation devices and networking. The board can work in harsh environment supporting -40 to +85 Celsius extended temperature operation for industrial embedded applications.

The TI AM335x consists of 6 pin-pin compatible devices (AM3352, AM3354, AM3356, AM3357, AM3358 and AM3359) with various options including speed grades, packages, graphics and peripherals. MYIR is using the 15x15 mm, 0.8-mm ball pitch, ZCZ package AM335x ARM CPU on the MYC-AM335X CPU Module which is an SOM (System on Module) and has the core components AM335x processor, 512MB DDR3 SDRAM, 512MB Nand Flash and Gigabit Ethernet PHY chip on board and can be served as the core of your embedded system. It has two 2.0mm pitch 60-pin male expansion connectors, one 2.0mm pitch 26-pin interface and one 2.0mm pitch 10-pin interface to allow extension of all the controller signals and ports to the base board through headers and connectors, thus exposing more features of the AM335x Cortex-A8 Processors.

The MYD-AM335X base board has extended many features and peripherals with the support of the MYC-AM335X SOM and some extended controller chips including two serial ports, four USB Host ports, one USB OTG port, dual Gigabit Ethernet ports, one CAN, one RS485, one Micro SD, HDMI, LCD, Touch screen and more others.

User can integrate a different MYC-AM335X SOM on the same base board, thus making six variants of AM335x evaluation boards.


MYD-AM3359 Development Board – with MYC-AM3359 CPU Module for TI AM3359
MYD-AM3358 Development Board – with MYC-AM3358 CPU Module for TI AM3358
MYD-AM3357 Development Board – with MYC-AM3357 CPU Module for TI AM3357
MYD-AM3356 Development Board – with MYC-AM3356 CPU Module for TI AM3356
MYD-AM3354 Development Board – with MYC-AM3354 CPU Module for TI AM3354
MYD-AM3352 Development Board – with MYC-AM3352 CPU Module for TI AM3352



The MYD-AM335X series ARM Cortex-A8 boards have many features in common only with some differences depending on the AM335x Cortex-A8 CPU features. You can get to know the differences from above image.
The MYD-AM335X board comes with Linux 3.1.0, Android 2.3.4 and Windows CE7 software packages, detailed documents, necessary cable accessories as well as optional 4.3- and 7-inch LCD (with touch screen) to provide an AM335x starter kit and enable a quickly start of evaluation of AM335x Cortex-A8 MPUs.

Features Mechanical Parameters

• Dimensions: 130mm x 100mm (base board), 70mm x 50mm (CPU Module)
• PCB Layers: 4-layer design (base board), 6-layer design (CPU Module)
• Power supply: +5V/2A (base board), +3.3V/0.8A (CPU Module)
• Working temperature: 0~70 Celsius (commercial grade) or -40~85 Celsius (industrial grade)

Note: Our products are delivered of commercial grade (0~70 Celsius) by default. Anyhow the MYD-AM335X boards based on TI AM335x ARM Cortex-A8 processors can work for industrial applications working in harsh environment with working temperature ranging from -40 Celsius to 85 Celsius. Please contact MYIR for price and availability of products of industrial grade if you needed.

OS Support

• Linux 3.1.0
• Android 2.3.4
• Windows CE7

The MYD-AM335X Controller Board (MYC-AM335X CPU Module)

Processor

• TI AM3352, AM3354, AM3356, AM3357, AM3358, AM3359 (15x15 mm, 0.8-mm ball pitch, ZCZ package)
  • 800-MHz ARM Cortex-A8 32-bit RISC MPU (Up to 1GHz)
  • NEON™ SIMD Coprocessor
  • 32KB/32KB of L1 Instruction/Data Cache with Single-Error Detection (parity)
  • 256KB of L2 Cache with Error Correcting Code (ECC)
  • SGX530 Graphics Engine
  • Programmable Real-Time Unit Subsystem

Memory

• 512MB DDR3 SDRAM
• 512MB Nand Flash

Peripherals and Signals Routed to Pins

On-board Gigabit Ethernet PHY
One power indicator (Red LED)
One user LED (Green)
Two 2.0mm pitch 60-pin expansion connectors can carry out interfaces below

• 2 x USB2.0 OTG ports
• 6 x Serial ports
• 2 x I2C
• 1 x SPI
• 7 x ADC
• 2 x PWM
• 3 x SDIO

One 2.0mm pitch 26-pin expansion connector
One 2.0mm pitch 10-pin expansion connector

The MYD-AM335X Base Board

• Serial ports
  • 1 x 3-wire RS232 Debug serial port (DB9)
  • 1 x 3-wire RS232 serial port (UART1)
  • 1 x RS485 (with isolation)
• USB
  • 4 x USB2.0 Host ports
  • 1 x USB2.0 OTG ports
• 2 x 10/100/1000Mbps Ethernet interfaces
• 1 x CAN interface (with isolation)
• 1 x TF card slot
• 1 x HDMI interface
• 1 x LCD interface (16-bit true color, supports optional 4.3-inch and 7-inch TFT LCD)
• 1 x 4-wire resistive touch screen interface
• 1 x Audio input port (3.5mm jack)
• 1 x Stereo Audio output port (3.5mm jack)
• 4 x Buttons (1 x Reset button, 3 x User buttons)
• 1 x Power indicator (Red LED)
• 2 x 2.0mm 20-pin expansion connectors
  • 7 x ADC
  • 1 x SPI
  • 2 x I2C
  • 4 x UART
