DC axial fan 120x120x25mm 24V 2W 34dBA 127.5m³/h – Sunon EEC0252B3-000U-G99
search
  • DC axial fan 120x120x25mm 24V 2W 34dBA 127.5m³/h – Sunon EEC0252B3-000U-G99
  • DC axial fan 120x120x25mm 24V 2W 34dBA 127.5m³/h – Sunon EEC0252B3-000U-G99
ID: 1193597
€10.67
Tax included

€8.68 tax excl.

The Sunon EEC0252B3-000U-G99 fan combines quiet operation, efficiency and compact dimensions, making it a suitable solution for reliable cooling of electronic and industrial devices. Equipped with a brushless DC motor, ball bearings and diagnostic functions, it ensures long service life and precise monitoring of operation, even in demanding environmental conditions. Sunon EEC0252B3-000U-G99

24h
Available
Available quantity: 4


Free shipping

free shipping in Poland for all orders over 500 PLN



Same day shipping

If your payment will be credited to our account by 11:00



14 days for return

Each consumer can return the purchased goods within 14 days

Description

Sunon EEC0252B3-000U-G99 axial fan designed for DC voltage supply in the range of 10...27.6 V DC, with optimal operation at 24 V DC. The model with dimensions of 120 x 120 x 25 mm, equipped with a brushless DC motor and ball bearings, offers a capacity of 127.5 m³/h at a rotational speed of 2200 rpm (±10%) and generates noise at the level of 34 dBA. The housing and impeller are made of thermoplastic with a flammability class of UL94V-0 and compliance with the ECE R-118 standard. The fan is equipped with an auto-restart function and a type F (Frequency Generator) signal output, enabling monitoring of rotational speed. Designed for applications requiring reliable cooling, including automation systems, power supplies, switchboards and electronic devices.

Features

  • Dimensions 120 x 120 x 25 mm
  • Operating voltage range 10...27.6 V DC
  • Nominal voltage 24 V DC
  • Power consumption 2 W (±15%)
  • Rated current 84 mA (±15%)
  • Efficiency 127.5 m³/h
  • Rotation speed 2200 rpm (±10%)
  • Static pressure 4.07 mm H₂O
  • Noise level 34 dBA
  • Brushless DC motor
  • Auto restart function
  • Ball bearing type
  • Signal output type F (Frequency Generator)
  • Thermoplastic housing and rotor
  • Flammability class UL94V-0, ECE R-118 compliant
  • Insulation class A
  • Minimum insulation resistance 10 MΩ
  • Operating temperature range -10...70°C
  • Leads wire x3 (length 0.33 m, 24 AWG)
  • Gross weight 169.46 g
1193597

Data sheet

Voltage
10 - 27,6 V
Power
2 W
Length
120 mm
Width
120 mm
Height
25 mm
Weight
Other
Noise level
34 dBA
Air flow efficiency
127,5 m³/h
Rated current
84 mA
Fan type
Axial
