Category: Qwiic peripheral modules (SparkFun)
Qwiic (SparkFun) Peripheral Modules - Fast Integration and Versatility
Qwiic (SparkFun) modules are modern solutions enabling quick connections between components without the need for soldering, significantly speeding up electronic projects. With modules like the Qwiic MultiPort - a 4-port splitter, users can easily expand systems with new sensors, relays, and peripherals, offering flexibility in building applications. The Qwiic system supports both beginners and advanced designers, providing a broad range of products tailored to different project needs.
There are 170 products.
Flexible 4-core cable, 200 mm long, terminated on both sides with a Qwiic plug. Sparkfun PRT-17258
Qwiic to Grove adapter cable, 100 mm long. Enables interoperability between the SparkFun Qwiic Connect system and Seeed Studio I2C-based Grove boards. SparkFun PRT-15109
End module of the communication system based on QwiicBus. It allows you to extend the range of the I2C bus. SparkFun COM-16988
SparkFun Qwiic kit. Contains 10 wires of different lengths and tips. It allows you to connect Qwiic modules to a programming platform or to a prototype board. SparkFun KIT-15081
Module with 9-axis IMU ICM-20948 sensor. The chip is an integrated 3-axis accelerometer, gyroscope and magnetometer and a digital motion processor DMP (Digital Motion Processor). Communication via I2C or SPI. SparkFun SEN-15335
Flexible 4-core cable, 50 mm long, terminated on both sides with a Qwiic plug. Sparkfun PRT-17260
Hub with Qwiic connectors that allows you to connect several boards to the evaluation kit. There is no built-in control system, but only splits one connector into 3 more. SparkFun BOB-18012
A mini module with a Qwiic connector designed for Raspberry Pi minicomputers. Qwiic SHIM uses a unique connector that snaps into the GPIO connector for a secure, solder-free connection. SparkFun DEV-15794
Module with 24-bit ADC NAU7802 converter. It enables reading data from strain gauges and scales. I2C interface. SparkFun SEN-15242
Module with a voltage level converter 3.3 V - 5 V intended for use in the Qwiic system. It has a built-in Step Up converter providing power supply with a voltage of 5 V and a current of up to 100 mA. SparkFun SPX-17238
Shield with Qwiic connectors designed for Raspberry Pi minicomputers. It allows you to easily connect the minicomputer with the Qwiic sensor system. SparkFun DEV-15945
Module with relay up to 5.5 A and 240 V AC controlled by the I2C interface. SparkFun COM-15093
Flexible Qwiic cable, 150 mm long. On one side it is terminated with a female Qwiic connector, and on the other side with single female goldpin connectors. SparkFun PRT-17261
Module with 4 Qwiic connectors for Teensy 4.1, Teensy 3.6, and Teensy 3.5 boards. Communication via the I2C interface. SparkFun DEV-17156
Module with BME680 sensor for measuring environmental conditions such as concentration of volatile organic compounds (VOC), atmospheric pressure, temperature and humidity. I2C or SPI communication. SparkFun SEN-16466
BMA400 3-axis accelerometer module with a measurement range of up to ±16g. The board is equipped with a Qwiic connector and communicates via an I2C interface. SparkFun SEN-21207
Heart rate monitor module based on the popular MAX30101 and MAX32664. The board is equipped with connectors compliant with the Qwiic standard. SparkFun SEN-15219
Module with 512 kbit (64kB) EEPROM. Communication is via the I2C interface. The module has 3 jumpers to select one of 8 addresses. SparkFun COM-18355
Module with EEPROM memory, capacity 512 kbit (64kB). Communication takes place via the I2C interface. The module has 3 jumpers that enable selection of one of 8 addresses. SparkFun SPX-14764
Versatile Modules for Advanced Projects
The Qwiic system allows for easy expansion of electronic setups through modules like the Qwiic 9DoF IMU Breakout with a 9-axis IMU ICM-20948 sensor, used for precise motion and orientation measurements. Another useful component is the Qwiic Boost - a voltage level converter (3.3/5V), which ensures compatibility between devices with varying voltage requirements. Flexible cables, such as the Qwiic Female-Female 4-pin 200mm cable, allow convenient connection of various modules.
Easy Integration with Raspberry Pi and Control Systems
The Qwiic SHIM is a miniature module with a Qwiic connector, designed for Raspberry Pi, simplifying the process of adding additional sensors and peripherals. Modules like the Qwiic Single Relay with a 5.5A/240VAC relay are ideal for automation and control projects, providing reliable operation of electrical devices. Additionally, the QwiicBus EndPoint supports extensive communication systems, functioning as the endpoint module in large QwiicBus installations.
Qwiic System - Fast Prototyping Without Soldering
The Qwiic (SparkFun) system is designed for users who want to minimize the time needed for prototyping. These modules eliminate the need for soldering, making work faster and more efficient. The wide selection of components allows for the integration of various functionalities, from signal processing to automation and measurement. With simple connectors and compatibility with many popular platforms, the Qwiic system is an excellent solution for both hobbyists and professionals.
