ADC and DAC Converters: Essential Components of Modern Electronics
Analog-to-digital (ADC) and digital-to-analog (DAC) converters are key elements in modern electronic systems, enabling the conversion of analog signals to digital and vice versa. Our offering includes a wide range of converters and converter modules that meet the needs of both hobbyists and professionals. From modules with touch panel controllers and converters with headphone amplifiers to audio modules with converters – there is something for everyone. These converters are essential in applications such as voltage and current monitoring for Raspberry Pi, allowing precise control and monitoring in various projects. With our advanced solutions, your systems will be able to operate more efficiently and accurately.
There are 53 products.
Module with 4-channel ADC ADS1115 converter. The system enables analog voltage conversion for single signals and differential signals with 16-bit resolution. I2C communication
Audio module based on a 32-bit PCM5102A DAC converter intended for cooperation, among others with Raspberry Pi minicomputers. Communication via the I2S interface. GY-PCM5102
Module with 4-channel ADC ADS1015 converter. The system enables analog voltage conversion for single signals and differential signals with 12-bit resolution. I2C communication
Audio module designed for Teensy 3.2, 3.5, 3.6 and 4.0. It uses the PT8211 16-bit digital to analog converter (DAC) chip. PJRC PT8211-AUDIO-KIT
A 2-channel DAC converter module with an output voltage range from 0 to 10 V. It is powered by 3.3 V to 5 V and communicates via I2C interface (Gravity connector). It is used as a controller in industrial applications. DFRobot DFR0971
Gravity: I2C ADS1115 The 16-Bit ADC Module is an analogue-to-digital converter module for Arduino and Raspberry Pi. This module uses 16-bit ADC ADS1115 and is powered by 3.3 ... 5V. DFRobot DFR0553
A 16-bit DAC converter module designed to work with M5Stack sets. It enables the conversion of analog signals into a digital signal. M5Stack ADC Unit
Module with 12-bit DAC converter and built-in EEPROM memory. The module is supplied with the voltage from 2.7 to 5.5V, the I2C interface is used for communication. SparkFun BOB-12918
ADC converter module with 7 measurement channels (measuring 0-5V, 0-10V voltage and 4-20 mA current). Communicates via RS485 industrial interface using Modbus RTU protocol. R4AVA07
Module with 24-bit ADC NAU7802 converter. It enables reading data from strain gauges and scales. I2C interface. SparkFun SEN-15242
A module with a 24-bit ADC converter HX711, which allows you to read data from strain gauges and scales. It communicates via the serial interface. SparkFun SEN-13879
The ADC module allows you to measure the voltage and provide the result in digital form, it has a built-in 4-channel ADS1015 transmitter. Modally MOD-55
DAC converter module with current output in the range of 0 to 25 mA. It is powered by 18 V to 24 V and communicates via I2C interface (Gravity connector). It is used as a controller in industrial applications. DFRobot DFR0972
Module with 8-bit ADC and 8-bit DAC. It allows you to measure voltage and generate an analog signal. Communicates via I2C
Gravity module designed based on the GP8501 system. It is a two-channel DAC (analog-to-digital) converter with PWM communication that offers an output signal with 8-bit resolution and 0.5% accuracy. It allows you to generate analog signals with a voltage range from 0 to 2.5 V or from 0 to VCC. DFRobot DFR1037
Gravity: I2C 12-Bit DAC is a module with 12-bit DAC and built-in EEPROM memory. The module is powered by 3.3 ... 5V for communication used by the I2C interface. DFRobot DFR0552
3-channel voltage and current monitoring module designed to work with the Raspberry Pi. It can measure voltage ranging from 0 to 26 V and voltage ± 3.2 A. SB Components 20805
Gravity module designed based on the GP8413 system. It is a two-channel DAC (analog-to-digital) converter with I2C communication that offers an output signal with a resolution of 15-bit and an accuracy of 0.2%. It allows you to generate analog signals with a voltage range from 0 to 10 V or 0 to 5 V. DFRobot DFR1073
Gravity module designed based on the GP8101S system. It is a single-channel DAC (analog-to-digital) converter with PWM communication that offers an output signal with 8-bit resolution and 0.2% accuracy. It allows you to generate analog signals with a voltage range from 0 to 10 V or 0 to 5 V. DFRobot DFR1036
Gravity module designed based on the GP8503 system. It is a two-channel DAC (analog-to-digital) converter with I2C communication that offers an output signal with 12-bit resolution and 0.1% accuracy. It allows you to generate analog signals with a voltage range from 0 to 2.5 V or from 0 to VCC. DFRobot DFR1034
Functionality and Applications of Converters
Analog-to-digital (ADC) converters transform analog signals into digital ones, which is essential in modern systems where precise monitoring and data analysis are required. Converter modules allow the integration of these components into various applications, from audio systems to advanced measurement setups. These converters are ideal for use in home automation, medicine, telecommunications, and many other fields where accuracy and reliability are crucial.
Specialized Modules
Our offer also includes converter modules equipped with additional features, such as touch panel controllers. These modules make it possible to create interactive control systems that are intuitive and easy to use. They are indispensable in modern multimedia applications where user comfort and precision are important. Another example is converters with headphone amplifiers, which provide excellent sound quality in audio devices.
Advanced Audio Modules and Monitoring
For audio enthusiasts, we have prepared audio modules with converters that allow precise conversion of digital signals to analog, which is crucial in high-quality audio systems. These modules are ideal for use in hi-fi systems, musical equipment, and professional recording studios. Additionally, we offer solutions for voltage and current monitoring for Raspberry Pi, allowing precise control of electrical parameters in various projects, increasing their efficiency and safety. By investing in our converters, you gain access to the latest technologies that will enhance the quality and efficiency of your systems.
