New products
zł67.45 tax excl.
Module with 4-channel ADC ADS1115 converter. Equipped with a STEMMA QT connector, it communicates via the I2C interface. Adafruit 1085
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
Module with 4-channel ADC ADS1115 converter, which allows you to read voltages in single signal mode or differential signals with a sampling frequency of up to 860 Hz and a resolution of 16 bits. It is ideally suited for fast and precise DC voltage measurement over a wide range. It has a built-in programmable amplifier (up to x16), allowing you to amplify low-amplitude signals to the full range. The module is compatible with 3.3 V and 5 V controllers, and communication is via the I2C interface (STEMMA QT connector). Full documentation is available on the product page.
Features
- ADC ADS1115 chip
- 16-bit precision
- 4 single or 2 differential channels
- Programmable gain
- Sampling frequency from 8 Hz to 860 Hz
- STEMMA QT/Qwiic connector
- I2C interface
- I2C address: 0x48 to 0x4B
- Supply voltage: 2 to 5.5 V
- Dimensions: 25.4 x 17.8 x 4.6 mm
Kit contains
- STEMMA QT ADS1115 16-Bit ADC
- Straight 16-pin male connector
