DAC Audio Decoder Board - a module with a DAC converter for Raspberry Pi
search
  • DAC Audio Decoder Board - a module with a DAC converter for Raspberry Pi
  • DAC Audio Decoder Board - a module with a DAC converter for Raspberry Pi
  • DAC Audio Decoder Board - a module with a DAC converter for Raspberry Pi
  • DAC Audio Decoder Board - a module with a DAC converter for Raspberry Pi
ID: 1178450
5902186309944
zł352.97
Tax included

zł286.97 tax excl.

An audio module with a DAC converter designed to work with the Raspberry Pi. Supports I2S/DSD/Coaxial input, Analog/Coaxial/Optical/I2S output, and has 384K/32Bit decoding function. DFRobot DFR0941

4 weeks
On request
Kamami is the official distributor of DFRobot modules and development kits. All boards of this brand in our offer are original and come directly from the manufacturer.

Description

An audio module with a DAC converter designed to work with the Raspberry Pi. Supports I2S/DSD/Coaxial input, Analog/Coaxial/Optical/I2S output, 384K/32Bit decoding function and unique DSD clock jitter eliminator. The decoder board supports decoding of I2S and DSD digital audio signals coming from the Raspberry Pi, and can also decode external signals (configuration via buttons).

The board uses two LDO stabilizers for separate power supply of analog and digital circuits. High-capacity capacitors and tantalum capacitors are used for filtering and decoupling to ensure a stable and clean power supply.



The module is based on digital circuits, including PCM9211 (digital audio transceiver), PCM5122 (digital-to-analog converter), DS90LV047A (fast differential driver) and a crystal oscillator. The built-in OLED display can display the track's current sampling rate, the current decoder board input signal format and the I2S interface output format.

The module is perfect for building a high-quality audio system.

Features

  • Analog audio: RCA jack/headphones 32K to 384K/32Bit
  • Frequency Response: 20 to 20 KHz
  • Output level: 2 Vrms
  • Signal to noise ratio (SNR): 120dB
  • Coaxial connector: PCM 32K - 192K / 24Bit, DOP DOP64
  • PCM 32K - 192K / 24Bit output, DOP DOP64
  • I2S: PCM 32K - 384K / 32Bit, DOP DOP64 / DOP128, DSD DSD64 / DSD128
  • Voltage: 5V (can be powered from the Raspberry Pi motherboard or from the DC socket on the DAC board)
  • Rated current: 300 mA
  • Dimension: 56 x 65 mm
  • Support for Raspberry Pi model: Raspberry Pi 3B+/4B
  • Supporting systems: Volumio, Moode, piCorePlayer, RuneAudio

Kit contains

  • Raspberry Pi DAC Audio Decoder Board
  • Set of spacers and bolts
1178450

Data sheet

Compatible with
Raspberry Pi 5/4/3/2/1 A/B, Zero/Zero 2 H/WH
