Category: Other logic analyzers
The logic analyzer is an indispensable tool in the workshop of modern electronics. They enable registration and display of waveforms registered in digital systems
There are 15 products.
Troubleshooting tool that communicates between a PC and any embedded device over 1-,2-,3-wire, UART, I2C, SPI, and HD44780 LCD protocols - all at voltages from 0-5.5VDC. Eliminates a ton of early prototyping effort when working with new or unknown chips. TOL-12942
This is an interface cable for the Bus Pirate, designed to connect to its 2x5 I/O header. The cable’s connector is composed of two rows of five 0.1" spaced pins. CAB-09556
16-channel logic analyzer with a maximum sampling frequency of 100 MHz. It can decode data under most popular communication protocols. Works with Windows systems. LA1010
16-channel logic analyzer with a sampling frequency of 200 MHz. It can decode data under most popular communication protocols. Works with Windows systems. Seeed Studio 109990065
A multifunctional device (computer attachment) that combines a 2-channel digital oscilloscope and a 16-channel logic analyzer. Hantek6022BL
Acrylic housing designed for the MZ OpenScope device (410-324). It helps protect the device from damage to everyday use or during travel. Digilent 240-133
Compact, 4-channel logic analyzer with a sampling frequency of 100 MHz with a 2.8 "LCD display. It is used to analyze the logic relationships of digital systems. Seeed Studio 109990365
32-channel logic analyzer with a sampling frequency of 500 MHz. It can decode data under most popular communication protocols. Works with Windows, Linux and Mac OS systems. LA5032
16-channel logic analyzer with a maximum sampling frequency of 1 GHz. It can decode data under most popular communication protocols. Works with Windows, Mac OS and Linux. DSLogic U3Pro16
16-channel logic analyzer with a sampling frequency of 500 MHz. It can decode data under most popular communication protocols. Works with Windows systems. LA5016
16-channel logic analyzer with a maximum sampling frequency of 400 MHz. It can decode data under most popular communication protocols. Works with Windows, Mac OS and Linux. DSLogic Plus
High resolution data logger, equipped with eight analog channels, two power sources, function generator, eight digital I/O and wireless connection. Digilent 471-028
No product available!
High resolution data logger, equipped with eight analog channels, two power sources, function generator, eight digital I/O and wireless connection. Kit with accessory. Digilent 471-028
No product available!
30-wire connection cable for the OpenScope MZ measuring adapter. It allows pins to be connected to the 2x15 male connector. The cable also allows you to easily connect the attachment to other sets. Digilent 310-099
No product available!
Adapter with screw terminals for use with the OpenLogger data logger. Provides access to screw terminals to 8 analog inputs, 8 digital I/O, wave generator and power pins. Digilent 410-388
No product available!
