High-precision AD HAT with 32-bit ADC for Raspberry Pi - Waveshare 18983
ID: 583762
5906623439515
zł157.70
Tax included
zł128.21 tax excl.
Module with a 10-channel ADC ADS1263 converter with a resolution of 32-bits designed to work with the minicomputer Raspberry Pi and Jetson Nano. Waveshare High-Precision AD HAT
Description
Module with a 10-channel ADC ADS1263 converter with a resolution of 32-bits designed to work with the minicomputer Raspberry Pi and Jetson Nano. It enables the measurement of voltage in the range from -2.5 V to 2.5 V (differential inputs) or from 0 to 5 V with high precision and low noise level. The chip offers a sampling rate of 38.4 kSPS, uses a built-in 24-bit auxiliary ADC and an internal test signal. The board has connectors compatible with Waveshare sensors and a connector with screw terminals. The module is controlled by the SPI interface, which is available on a 40-pin connector compatible with Raspberry Pi and on a 10-pin connector that allows communication with other evaluation kits. Full documentation with examples is available on the Wiki website.
| 1. Raspberry Pi GPIO header | 7. ADC ground reference configuration |
| 2. AD input (screw terminal) | 8. 7.3728M crystal |
| 3. AD input (header) | 9. Power supply section |
| 4. Control input (header) | 10. RTD section |
| 5. Power configuration resistor | 11. Input filtering |
| 6. RTD configuration resistor | 12. ADS1263 |
Features
- ADS1263 chip
- 10 channels
- 32-bit resolution
- Sampling rate 38.4 kSPS
- Input voltage: -2.5V to 2.5V or 0 to 5V
- Low noise level
- Built-in 24 bit auxiliary ADC
- Internal ADC test signal, IDAC, internal reference voltage 2.5V
- 8 x GPIO multiplexing, PGA (32 times)
- Built-in AD connector input, compatible with Waveshare sensor pinout
- Built-in input with AD screw terminals
- Built-in control connector (facilitates the module control by other boards)
- Three-wire RTD circuit, started by soldering a 0R resistor
- SPI interface
- Dimensions: 65 x 30.5 mm
Kit contains
- High-Precision AD HAT module
- Set of screws
