ID: 1200988
zł271.41
Tax included

zł220.66 tax excl.

This 25W, 24VDC switching AC/DC power supply is designed for industrial and automation applications. Equipped with thermal, short-circuit, and overvoltage protection, it ensures safe and reliable operation. It supports parallel, dual, and series configurations, and its narrow 32mm housing allows for easy mounting on a 35mm DIN rail. The power supply complies with EN 60950-1 and EN 61204-3 standards, as well as the RoHS directive (Finder 78.25.1.230.2482).

1 weeks
Awaiting delivery

Description

AC/DC Switching Power Supply is a compact and reliable power source designed for industrial and automation applications. It provides a stable 24 V DC output with a power of 25 W, sufficient to supply up to two complete device sets — for example, one OPTA module and five expansion modules. The power supply meets SELV (EN 60950) safety requirements, ensuring safe operation in low-voltage environments. It features low standby power consumption and high energy efficiency, which translates into long service life and energy savings. Integrated thermal, short-circuit, and overvoltage protections (with varistor) safeguard connected devices from damage. The unit supports parallel operation using an OR diode, as well as dual and series configurations for greater flexibility. Its compact housing — only 32 mm wide and 61 mm deep — allows easy mounting on a 35 mm DIN rail (EN 60715). Fully compliant with EN 60950-1 and EN 61204-3 standards and the RoHS directive, this power supply is an ideal choice for industrial control systems, building automation, and other professional applications.

Features

  • AC/DC switching power supply
  • Input voltage: 110–240 V AC
  • Output voltage: 24 V DC
  • Output power: 25 W
  • Output current: 1 A
  • Designed for SELV applications (EN 60950)
  • Can power 1 OPTA module + 5 expansion modules
  • Low standby power consumption
  • Thermal protection with automatic Vout disconnection
  • Short-circuit protection with automatic recovery
  • Overvoltage protection via varistor
  • Parallel (redundant) operation supported with OR diode
  • Dual and series connection capability
  • Dimensions: 32 × 61 mm
  • DIN rail mounting: 35 mm (EN 60715)
  • Compliance: EN 60950-1, EN 61204-3
  • RoHS compliant
1200988

Data sheet

Output voltage
24V
Output current
1A
Power
25 W

Manufacturer FINDER POLSKA SPÓŁKA Z OGRANICZONA ODPOWIEDZIALNOŚCIĄ Logistyczna 27, Sady 62-080 Tarnowo Podgórne Poland finder.pl@findernet.com

Responsible person FINDER POLSKA SPÓŁKA Z OGRANICZONA ODPOWIEDZIALNOŚCIĄ Logistyczna 27, Sady 62-080 Tarnowo Podgórne Poland formularz kontaktowy na stronie osoby odpowiedzialnej
