Power HD Mini Digital Servo HD-1810MG - 145° digital servo
ID: 195839
5906623485628
zł121.52
Tax included
zł98.80 tax excl.
Mini digital servo with metal gear. It has a range of motion of 145°. Pololu 1047
Description
Mini digital servo equipped with a metal gear. A standard PWM modeling signal is used for control. The servo has a range of motion of approximately 145°. The recommended operating voltage is 6 V and at this voltage the servo has a speed of 0.13 s/60° and a torque of 3.9 kg*cm. The cable is terminated with a standard JR/Futaba 3-pin connector. Perfect for small flying models.
Features
- Supply voltage 4.8 to 6 V
- Speed (no load)
- 4.8 V - 0.16 sec/60°
- 6V - 0.13s/60°
- Torque:
- 4.8 V - 3.1 kg*cm
- 6 V - 3.9 kg*cm
- Metal gear
- PWM control range: 750 to 2250 us
- Dimensions: 22.8 x 12 x 29.4 mm
- Weight: 16 g
Kit contains
- Power HD Mini Digital Servo HD-1810MG
- A set of draglines and mounting elements
195839
Data sheet
- Gear material
- Metal
- Torque
- 3,9 kg-cm
- Rozmiar serwa (seria)
- Mini
- Prędkość kątowa
- 0,13 s/60°
- Sprzężenie zwrotne
- Nie
- Praca ciągła 360°
- Nie
- Power supply voltage
- 4,8 - 6 V
- Weight
- 16g
