Finder 55.13.9.024.0000 - electromagnetic relay 24V 10A 3xCO PCB
ID: 1203874
zł33.97
Tax included
zł27.62 tax excl.
Miniature electromagnetic relay by Finder with 24 V DC coil, three changeover contacts rated 10 A and THT mounting for PCB. Finder 551390240000
Description
Miniature industrial electromagnetic relay from Finder Series 55 designed for mounting on printed circuit boards, equipped with three changeover contacts rated up to 10 A. The design enables use in consumer electronics, control systems, automation and industrial devices requiring reliable switching of signals and loads.
The 24 V DC coil operates within a range of 19.2 V to 26.4 V, ensuring stable performance in low-voltage systems. AgNi contact material and 4 kV insulation between coil and contacts enable safe operation in demanding environments.
Features
- Series: Finder 55
- Relay type: Electromagnetic
- Contact configuration: 3 changeover contacts
- Contact material: AgNi
- Rated contact current: 10 A
- Rated contact voltage: 250 V AC
- Coil voltage: 24 V DC
- Coil voltage range: 19.2 - 26.4 V
- Coil power: 1 W
- Coil resistance: 600 Ω
- Current consumption: 40 mA
- Holding voltage: 12 V
- Drop-out voltage: 2.4 V
- Coil-contact insulation: 4 kV
- Mounting: THT PCB
- Electrical life: 200000 cycles
- Operating temperature: -40°C ~ 85°C
- Dimensions: 20.7 x 35.8 x 27.7 mm
1203874
Data sheet
- Output current
- 10A
- Number of channels
- 3
- Executive element
- Przekaźnik elektromagnetyczny
- Coil voltage
- 24 VDC
Manufacturer FINDER POLSKA SPÓŁKA Z OGRANICZONA ODPOWIEDZIALNOŚCIĄ Logistyczna 27, Sady 62-080 Tarnowo Podgórne Poland finder.pl@findernet.com
Responsible person FINDER POLSKA SPÓŁKA Z OGRANICZONA ODPOWIEDZIALNOŚCIĄ Logistyczna 27, Sady 62-080 Tarnowo Podgórne Poland formularz kontaktowy na stronie osoby odpowiedzialnej
