KAmod TPS5401- 5V Miniature 5V Switching Voltage Regulator with TPS5401 Chip
ID: 1194488
5906623496648
zł11.91
Tax included
zł9.68 tax excl.
KAmod TPS5401 is a compact Step-Down switching regulator based on the energy-efficient TPS5401 chip, providing an output voltage of 3.3 V, 5 V, or 12 V (depending on the version). It supports a maximum continuous current of 0.5 A and a wide input voltage range of 4...42 V, while its 2.54 mm pitch terminals allow for easy mounting.
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
The KAmod TPS5401 is a compact Step-Down switching regulator module based on the energy-efficient TPS5401 chip. The output voltage can be 3.3 V, 5 V, or 12 V, depending on the module version. The maximum continuous output current is 0.5 A, and the input voltage can be up to 42 V. The module’s pins are arranged with a 2.54 mm pitch, allowing for soldering wires or goldpin headers.
Features
- Module with a fixed output voltage of 5 V
- Continuous output current of 0.5 A, with a temporary overload capacity of up to 0.8 A
- Wide input voltage range: 4...42 V
- EN control input for enabling and disabling the regulator
- Very low current consumption with no load: approximately 1 mA
- Extremely low current consumption in shutdown mode: approximately 1 µA
- Switching frequency: 700 kHz
- Soft-Start function for smooth voltage ramp-up when powering on
- Adjustable input voltage threshold, below which the regulator is disabled (no output voltage)
- PCB with 2.54 mm pitch contacts for soldering wires or goldpin headers
- Dimensions: 14.2 x 12.7 x 5 mm
Included in the set:
- Pre-assembled and tested module
1194488
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Other products in the same category (14)
The LM7809 9 V 1.2 A linear stabilizer module is a reliable and easy-to-use voltage stabilization solution for all electronics projects. Thanks to its solid construction, built-in protections and high efficiency, this module provides a safe and constant 9 V power supply, being an invaluable component in the work of every electronics engineer
zł7.61 24hAvailable quantity: 27 Available No product available!
KAmod TPS5401 is a compact Step-Down switching regulator based on the energy-efficient TPS5401 chip, providing an output voltage of 3.3 V, 5 V, or 12 V (depending on the version). It supports a maximum continuous current of 0.5 A and a wide input voltage range of 4...42 V, while its 2.54 mm pitch terminals allow for easy mounting.
zł12.79 24hAvailable quantity: 95 AvailableKAmod TPS5401 is a compact Step-Down switching regulator based on the energy-efficient TPS5401 chip, providing an output voltage of 3.3 V, 5 V, or 12 V (depending on the version). It supports a maximum continuous current of 0.5 A and a wide input voltage range of 4...42 V, while its 2.54 mm pitch terminals allow for easy mounting.
zł11.91 24hAvailable quantity: 99 AvailableAn isolated DC-DC converter that can be powered from 36 to 72 V DC and supplies 5 V DC and up to 20 A. The device is supplied in an IP65 enclosure. SparkFun COM-18733
zł179.90 4 weeks No product available!
A simple DC power supply with an output voltage of 12.6 V DC and a current of 10 A. The device can be powered with a voltage of 8 to 36 V DC. It can be used to charge Li-Ion batteries, it will also work well for powering devices such as LED lighting. SparkFun PRT-18722
zł159.00 4 weeks No product available!
5.0V Power Supply Module Board with Red Indicators, AMS1117-5.0V, RoHS
