New products
New products
zł218.70 tax excl.
A base board dedicated to Raspberry Pi CM4 modules. It is equipped with connectors for all available interfaces, in addition there is an RTC chip on the board Grove ports dedicated to the connection of external expansion modules. Cytron CM4 Maker Board
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
A base board designed for Raspberry Pi CM4 modules. It is equipped with special connectors that allow the module to be connected and all the interfaces of the CM4 module to be brought out, including 4 USB2.0 slots, an Ethernet port, HDMI, DSI, CSI and a 3.5mm Jack audio output.
The Maker Board is additionally equipped with a real-time clock (RTC) chip, a voltage backup battery socket and a 40-pin GPIO connector compatible with HAT modules.
Expanding the capabilities of the board is facilitated by a number of connectors, including 5 Grove ports with GPIO, PWM, UART and I2C interfaces, a buzzer and 10 LEDs and 3 buttons at the user's disposal.
NThe top of the board also features an M.2 connector for connecting additional modules or a drive and a micro SD card slot. The board is powered by a wide range of voltages from 7 V to 18 V via the DC connector or 5 V via the USB Type C connector. The user can also easily manage the board's switching on and off thanks to the built-in POWER button.
With such a rich set of functionalities, the CM4 Maker Board will meet the expectations of even the most demanding users. Full documentation along with numerous examples of use are available on the product page.
Pinout
Features
- CM4 connector: suitable for all variants of the Raspberry Pi CM4 module (not included)
- 10 x GPIO LED
- MicroSD card slot
- CSI camera port
- DSI display port
- 5 x Grove ports
- 2 x GPIO ports (GPIO 5, 6 and 23, 24)
- PWM port (GPIO 12, 13)
- UART port (GPIO 14, 15)
- I2C port (GPIO 2, 3)
- Maker port (4-pin JST-SH connector)
- 3 x User buttons
- Analogue audio output
- Piezo buzzer
- Buzzer mute switch
- 2 x power buttons
- RTC battery socket
- PCF85063A RTC
- External power button connector
- Boot switch
- M.2 connector
- M.2 mounting hole
- USB-C
- HDMI
- 4 x USB 2.0 Host
- Gigabit Ethernet
- GPIO connector
- DC power socket
- 4 x status LEDs
- Dimensions: 110 x 110 mm
Kit contains
- CM4 Maker Board
- 4 x rubber feet
You might also like
SoM Raspberry Pi CM4 with the SoC Broadcom BCM2711 SoC (4 x Cortex-A72) running at 1.5 GHz, 1 GB LPDDR4 RAM and 8 GB eMMC. Raspberry Pi CM4001008
SoM Raspberry Pi CM4 with the SoC Broadcom BCM2711 SoC (4 x Cortex-A72) running at 1.5 GHz, 1 GB LPDDR4 RAM, 8 GB eMMC and wireless connectivity. Raspberry Pi CM4101008
No product available!
SoM Raspberry Pi CM4 with the SoC Broadcom BCM2711 SoC (4 x Cortex-A72) running at 1.5 GHz, 2 GB LPDDR4 RAM and 16 GB eMMC. Raspberry Pi CM4002016
SoM Raspberry Pi CM4 with the SoC Broadcom BCM2711 SoC (4 x Cortex-A72) running at 1.5 GHz, 2 GB LPDDR4 RAM, 32 GB eMMC and wireless connectivity. Raspberry Pi CM4102032
