Telesto MAX10 FPGA Module - development board with Altera MAX10 (10M50DA)
ID: 1181039
zł3,293.71
Tax included
zł2,677.81 tax excl.
Development kit with Altera MAX10 (10M50DA) FPGA chip with built-in Flash memory and IO interface expansion connectors. Numato Lab NLFA1002B
Description
Development kit with Altera MAX10 (10M50DA) FPGA. It has built-in NOR Flash memory, which eliminates the need for external configuration memory. On the board there is a 2 Gb DDR3 RAM memory and the necessary elements needed to run the system, including switches, JTAG connector, USB connector and IO interface expansion connectors. The set will be used for prototyping, signal processing as well as creating and testing circuits. It can be used as an educational board. Full documentation is available on the product page.
Features
- MAX 10 FPGA (10M50DA)
- DDR3: 2 GB DDR3 (MT41J128M16HA-125)
- Internal flash memory
- 100 MHz LVDS oscillator
- Voltage stabilizers
- FPGA configuration via JTAG and USB
- FPGA - 150 IO
- Analog inputs - 8 IO
- All user IOs are matched in length and can be used as difference pairs
- Power supply: 12 V
- Dimensions: 83.8 x 57.54 mm
1181039
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
