SenseCAP M2 Multi-Platform LoRaWAN Indoor Gateway (SX1302-4G) US915 Seeed Studio 114993079 is an 8-channel LoRaWAN gateway with a built-in 4G LTE modem, designed for operation in the US915 band. It supports multiple frequencies and network servers, enabling the creation of scalable IoT solutions for agriculture, smart cities, and environmental systems.

4 weeks
On request
Kamami is the official distributor of Seeed Studio modules and development kits. All products of this brand in our offer are original and come directly from the manufacturer.

Description

The SenseCAP M2 Multi-Platform LoRaWAN Indoor Gateway in the 4G connectivity version is designed for operation in the US915 band. Based on the SX1302 chip and MT7628 processor, it supports up to 8 channels and the LoRaWAN 1.0.3 protocol (Class A/B/C). With support for multiple frequency plans (including AU915, AS923, KR920) and Packet Forwarder/Basics™ Station modes, it enables integration with various network servers, including TTN, AWS, and ChirpStack.

The device features an integrated LoRaWAN server based on ChirpStack and a management interface through the local SenseCAP console available via Wi-Fi or Ethernet. It can be powered through a standard power adapter or PoE (IEEE 802.3af). The LTE Cat.4 modem version enables independent cellular connectivity in FDD LTE bands (including B2, B4, B5, B12, B66, B71) as well as WCDMA. Thanks to its compact design and the option to expand with an outdoor enclosure, the gateway is suitable for a wide range of applications in agriculture, building automation, and environmental monitoring.

Properties

  • Semtech SX1302 baseband chip, 8 LoRa channels
  • Support for LoRaWAN 1.0.3 Class A/B/C
  • Support for US915 and other bands (EU868, AU915, AS923, KR920)
  • LoRa range up to 10 km, receiver sensitivity up to -139 dBm
  • Maximum transmit power up to 26 dBm
  • Processor MT7628 (MIPS24KEc, 580 MHz), 128 MB RAM, 32 MB Flash
  • Built-in 4G LTE modem (Cat.4 FDD, bands B2/B4/B5/B12/B13/B14/B66/B71)
  • Support for UMTS (WCDMA B2/B4/B5), DC-HSDPA up to 42 Mbps DL
  • Interfaces: Ethernet RJ45 (with PoE), USB Type-C (console), microSD (reserved), RP-SMA (antenna)
  • Antennas: LoRa 3 dBi, 4G main 3 dBi (PCB), 4G DIV 4 dBi (FPC)
  • Support for Wi-Fi 2.4 GHz 802.11 b/g/n
  • Power supply: 12 V DC or PoE (40–57 V DC, IEEE 802.3af)
  • Dimensions: 143.6 × 135 × 34 mm (without connectors), 150.6 × 135 × 34 mm (with connectors)
  • Operating temperature: from -20°C to +55°C
  • Humidity: 0–85% (non-condensing)

Included in the set

  • SenseCAP M2 Multi-Platform LoRaWAN Indoor Gateway
  • Power adapter
  • LoRa 3 dBi antenna
