CMOS Camera Module IMX219 with M12/CS mount for Jetson and Raspberry Pi CM4 – Seeed Studio 102110719
search
  • CMOS Camera Module IMX219 with M12/CS mount for Jetson and Raspberry Pi CM4 – Seeed Studio 102110719
ID: 1200450
zł83.62
Tax included

zł67.98 tax excl.

The Seeed Studio 102110719 camera module with a Sony IMX219 sensor supports both 15- and 22-pin CSI connectors, offering high flexibility in optics selection and applications. Designed for Jetson platforms and Raspberry Pi CM4, it is suitable for AI projects, surveillance, and robotics. Seeed Studio 102110719

4 weeks
On request
Kamami is the official distributor of Seeed Studio modules and development kits. All products of this brand in our offer are original and come directly from the manufacturer.

Description

The Seeed Studio CMOS IMX219 camera module features an 8 MP Sony IMX219 image sensor with high sensitivity, supporting both M12 and CS lens mounts. With two CSI connectors (15- and 22-pin), it can be integrated with a wide range of carrier boards, such as reComputer, reTerminal, and baseboards for Raspberry Pi Compute Module 4. Compatibility with M12, CS, and – using an adapter ring – C-mount lenses allows flexible optics selection for applications like video surveillance, DIY sports cameras, or facial recognition systems. The module delivers a still image resolution of 3280 × 2464 pixels and supports video modes 1080p30, 720p60, and 640×480p90. Its performance, image quality, and mounting flexibility make it suitable for many robotics, AI, and monitoring applications.

Properties

  • Sensor: Sony IMX219, 8 MP, BSI CMOS
  • Image resolution: 3280 × 2464 pixels
  • Video support: 1080p30, 720p60, 640×480p90
  • Lens mount: M12, CS; C-mount supported via 5 mm adapter ring
  • Dual CSI interfaces: 15-pin and 22-pin (FFC included)
  • Active sensor area: 3.68 × 2.76 mm (4.6 mm diagonal)
  • Pixel size: 1.12 × 1.12 μm
  • Sensitivity: 600 mV/lux-sec
  • SNR: 39 dB
  • Dynamic range: 69 dB
  • Power supply: 3.3 V (pin 15)
  • Output: 8/10-bit RGB RAW
  • Dimensions: 38 × 38 × 16 mm (without lens)
  • RoHS compliant

In the set

  • IMX219 camera module ×1
  • CS lens mount ×1
  • M12 lens mount ×1
  • 15-pin 125 mm FFC cable ×1
  • 22-pin 150 mm FFC cable ×1
  • Dust cap ×1
1200450

Data sheet

Resolution
8MPx
Interface
CSI
Sensor
IMX219
IR filter
No
Lens assembly
M12/CS mount
