  • Wireless module Wio-E5 STM32WLE5JC LoRaWAN EU868/US915 - Seeed Studio 317990829
ID: 1200527
zł39.90
Tax included

zł32.44 tax excl.

The Wio-E5 STM32WLE5JC module with LoRa SX126x enables the creation of energy-efficient, long-range IoT solutions with LoRaWAN® support in the EU868, US915, and other bands. Equipped with peripheral interfaces and AT firmware, it ensures fast integration in industrial and environmental applications. Available in tape (cut tape/reel), optimized for production. Seeed Studio 317990829

4 weeks
On request
Kamami is the official distributor of Seeed Studio modules and development kits. All products of this brand in our offer are original and come directly from the manufacturer.

Description

The miniature Wio-E5 wireless module based on the STM32WLE5JC integrates an ultra-low-power ARM Cortex-M4 microcontroller with the LoRa SX126x transceiver. It supports a wide frequency range (including EU868, US915, AU915, AS923, KR920, IN865) and LoRaWAN® Class A/B/C protocols. Integrated AT firmware enables fast integration in IoT applications such as sensor nodes, remote metering, environmental monitoring, and smart city systems. With UART, I2C, ADC, and SPI interfaces, the module offers high design flexibility. Supplied in tape (cut tape or reel), ideal for mass production.

Properties

  • Processor: ARM Cortex-M4 (STM32WLE5JC)
  • Memory: 256 KB Flash, 64 KB SRAM
  • Frequency range: EU868, US915 and others
  • Supported modulations: LoRa, (G)FSK
  • Transmit power: up to 22 dBm
  • Receiver sensitivity: up to -137.5 dBm (SF12, BW125 kHz)
  • Link budget: 158 dB
  • Interfaces: UART (3x), I2C (1x), SPI (1x), ADC (1x), RFIO, NRST
  • Current consumption:
  • Tx + MCU: up to 111 mA @ 868 MHz / 22 dBm
  • Rx + MCU: 6.7 mA @ 868 MHz
  • Sleep mode: 2.1 µA
  • Supply voltage: 3.3 V typ.
  • Dimensions: 12 × 12 × 2.5 mm
  • Mounting: SMD, 28 pins (stamp hole)
  • Operating temperature range: -40°C to +85°C
  • Certifications: CE, FCC, IC, Telec, WPC, RCM
