MX-5566-10A - Molex Mini-Fit Jr. Connector Housing, 10-Pin, 4.2 mm Pitch
ID: 39287
5902186301108
zł3.90
Tax included
zł3.17 tax excl.
MX-5566-10A is a 10-position wafer socker from the Mini-Fit Jr. series by Molex designed for reliable power connections. Its 4.2 mm pitch, high current capability, and robust design make it widely used in computer power supplies, industrial electronics, and power distribution applications.
Description
MX-5566-10A is a connector housing from the Mini-Fit Jr. series manufactured by Molex, designed for wire-to-board and wire-to-wire connections in applications requiring higher current capability. The connector features 10 positions arranged in a 2×5 configuration with a 4.2 mm pitch, providing stable and reliable electrical connections in power distribution systems and industrial electronics.
The housing is used with crimp terminals that are attached to wires and then inserted into the connector body. The Mini-Fit Jr. system is widely used in computer power supplies, industrial equipment, and electronic systems requiring reliable power connections. Wafer socket 10 pin, straight, Mini-Fit 4.20 mm, RoHS.
Features
- Producer: MOLEX
- Connector type: wire-board
- Connector type: male
- Number of pins: 10
- Contact pitch: 4.2 mm
- Electrical assembly: THT
- Connector series: Mini-Fit Jr.
- Maximum current: 9 A
- Contact coating: tin-plated
- Flammability rating: UL94V-2
- Locking system: latch
- Layout of connectors: 2x5
39287
