Finder 80.41.0.240.0000 - modular time relay 1P 16A 24-240V AC/DC

Finder 32.21.7.012.4300 is a compact PCB relay with a sensitive 12 V DC coil, designed for control circuits with loads up to 6 A. It is used in electronic devices, automation systems, and low-current applications requiring reliability and a small footprint.

Finder 34.51.7.012.4010 is an ultra-slim electromagnetic relay with a width of 5 mm, featuring a single changeover contact (SPDT) and a 12 V DC coil. This relay has a maximum switching current of 6 A and low coil power consumption of 170 mW, making it suitable for applications in confined spaces on printed circuit boards.

Finder 11.31.0.024.0001 is a twilight switch with a light sensor, designed for automatic lighting control in low-voltage 24 V installations. It is suitable for both outdoor and indoor systems, offering simple adjustment of the switching threshold and high operational durability.

Finder 22.22.9.024.4000 is a modular installation relay equipped with two normally open (NO) contacts with a 20 A load capacity at 250 V AC. The relay is powered by a 24 V DC coil voltage and is designed for DIN rail mounting, facilitating easy integration into industrial automation systems.

Finder 38.52.7.024.0050 is a relay interface module with a 24 V DC coil, equipped with two changeover contacts (DPDT) with a load capacity of 8 A. It is designed for DIN rail mounting and features screw terminals for easy installation.

Finder 7M.24.8.230.0210 is a compact, bidirectional single-phase energy meter with RS-485 and NFC communication, designed for advanced energy consumption monitoring. It is used in photovoltaic installations, building automation, and energy management in distributed systems.

Finder 22.22.8.230.4000 is a modular installation relay with two normally open (NO) contacts, each with a 20 A load capacity at 250 V AC, made of AgSnO₂ contact material. The relay is designed for DIN rail mounting (17.4 mm width) and operates with a 230 V AC coil voltage. Additionally, it features a test button for manual operation, facilitating diagnostics and easy control.

Finder 9D.01.5.080.0304 is a distribution block with a maximum current capacity of 80 A, featuring 3 inputs and 4 outputs for efficient power distribution in electrical installations. Designed for mounting on a 35 mm DIN rail, it supports wires with cross-sections ranging from 2.5 to 16 mm², offering flexibility in various industrial applications.

Finder 70.41.8.400.2030 is a voltage monitoring relay for three-phase AC networks with an interphase voltage of 380–415 V AC. The device allows for delay adjustment in the range of 0.5 to 60 seconds, and its output is a single-pole double-throw (SPDT) contact with a 6 A load capacity at 250 V AC. The relay is designed for DIN rail mounting and is equipped with screw terminals.

Finder 77.31.8.230.8050 is a solid-state relay (SSR) with a load capacity of 30 A, designed for DIN rail mounting. It features a 230 V AC control input and supports loads in the range of 48–480 V AC. Equipped with screw terminals, it ensures fast and reliable switching in industrial applications.

The Finder 94.84.2SPA socket is a base designed for DIN rail or panel mounting, equipped with "box clamp" screw terminals. It is compatible with relay series 55.34 and allows for easy and secure connection in industrial applications.

Finder 95.55SPA is a relay socket with spring terminals, designed for DIN rail mounting, compatible with relays from series 40 and 44. Equipped with 8 pins with a 5 mm pitch, it ensures quick and secure connections in industrial applications.

Finder 90.03SMA is an 11-pin relay socket with screw terminals, designed for DIN rail or panel mounting, and compatible with relays from series 60.13. It supports currents up to 10 A at 250 V AC, ensuring reliable connections in industrial applications.

The Finder 095.91.3 is a plastic retaining clip designed for sockets in the 95 series, such as 95.83.3 and 95.85.3, ensuring secure mounting of relays from the 40 and 41 series. Available in blue, this clip simplifies relay installation and removal while enhancing the reliability of electrical connections.

Finder 095.51 is a metal retaining clip for securing relays from series 40/44 in sockets from series 95. Enables firm mounting of the relay, minimizing the risk of dislodging due to vibration or transport. Particularly useful in industrial automation requiring secure fastening and RoHS compliance

Industrial Finder relay with 48 V DC coil, three changeover contacts rated at 10 A and designed for 8- and 11-pin socket mounting. Finder 601390480040
