- Out-of-Stock
3000mAh Battery
ID: 561767
Lithium Polymer rechargeable cell with a Protection circuit. Compatible with ODROID-C0
Description
3000mAh Battery compatible with ODROID-C0. Lithium Polymer rechargeable cell with a Protection circuit.
Features
- Capacity: 3000mAh / 3.7V
- Dimension: 56 x 48.5 x 10.2 mm (+/- 0.3mm tolerance)
- Lead wires: AWG#28, 50mm
- Connector: Molex 51021-0200
Protection Circuit Specification
- Over charge protection voltage : 4.28V
- Over charge release voltage : 4.08V
- Over discharge protection voltage : 3.0V
- Over current protection current : 3.5A
561767
Data sheet
- Output voltage
- 3.7V
- Battery type
- Li-Po
- Battery capacity
- 3000mAh
- Battery configuration
- 1S
- Number of cells
- 1
- Output/Connector
- Molex 51021-0200
- Length
- 56 mm
- Width
- 48,5 mm
- Thickness
- 10,2 mm
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
You might also like
Li-Po battery with a rated voltage of 3.7 V and a capacity of 1850 mAh, equipped with a PCM protection and a 2.5 JST-RCY connector. Akyga LP704452
