WEAH-338 - 3-Way Speaker Crossover 45 Hz-20 kHz 120 W
ID: 1187655
zł26.33
Tax included
zł21.41 tax excl.
WEAH-338 3-way speaker crossover designed to split an audio signal into low-, mid-, and high-frequency bands in speaker systems. The crossover supports up to 120 W, 4-8 Ω speaker impedance, and a frequency range from 45 Hz to 20 kHz. The product includes 1 crossover board. WEAH-338
Description
WEAH-338 distributes the audio signal between a woofer, midrange driver, and tweeter, supporting the construction or modification of 3-way speaker systems. The crossover handles up to 120 W and works with speakers rated at 4-8 Ω, with a specified frequency range from 45 Hz to 20 kHz. The manufacturer specifies compatibility with drivers up to 8 inches in diameter, while the PCB measures 110 x 67 x 24 mm. Components are mounted directly on the PCB, while the inductors are additionally secured with cable ties to limit movement during installation and operation.
Features
- Model: WEAH-338
- Type: passive speaker crossover
- Number of ways: 3
- Maximum power: 120 W
- Frequency range: 45 Hz-20 kHz
- Supported impedance: 4-8 Ω
- Intended for: woofer, midrange driver, and tweeter
- Recommended speaker diameter: up to 8"
- Dimensions: 110 x 67 x 24 mm
- Mounting hole spacing: 102 x 59 mm
- Quantity: 1 pc.
1187655
Data sheet
- Frequency
- 20 kHz
- Power
- 120 W
- Length
- 110 mm
- Width
- 67 mm
- Thickness
- 24 mm
- Impedance
- 4 Ω - 8 Ω
