UT195E - Universal multimeter by Uni-T
ID: 579611
5901890028820
zł478.67
Tax included
zł389.16 tax excl.
A universal multimeter allows you to measure direct and alternating voltage, direct and alternating current, resistance, capacity and frequency. Equipped with diode tester, circuit continuity test, automatic switch and backlight. Uni-T UT195E
Description
The Universal Uni-T UT195E multimeter measures DC and AC voltage, DC and AC, resistance, capacity and frequency. The multimeter is equipped with a diode tester, acoustic signal continuity test, automatic switch off and backlight as well as the Hold function.
| 1. Backlight sensor window | 6. Hook |
| 2. LCD | 7. Flashlight |
| 3. Function buttons | 8. Test probe stand |
| 4. Rotary switch | 9. Battery cabinet |
| 5. Input terminals | 10. Case |
The UT195 series are portable industrial digital multimeters with IP65 protection and 2 m drop resistance. UT195 resolution and precision have been improved compared to traditional multimeters to solve problems related to motor drives, equipment maintenance, electrical distribution and repair.
Features
- Parameters
- DC voltage 600mV/6V/60V/600V/1000V ± (0,5% + 3)
- AC voltage 600mV/6V/60V/600V/750V ± (1,0% + 3)
- LoZ ACV 600,0 V ± (2,0% + 3)
- DC current (A) 600μA/6mA/60mA/600mA/6A/20A ± (0,8% + 3)
- AC current (A) 600μA/6mA/60mA/600mA/6A/20A ± (1,0% + 3)
- Resistance (Ω) 600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ ± (0,8% + 2)
- Capacitance 6nF/60nF/600uF/6mF/60mF ± (3% + 5)
- Frequency 60,00 Hz do 10,00 MHz ± (0,1% + 4)
- Duty ratio 0,1% ~ 99,9% ± (2,0% + 5)
- Functions
- Display count 6000
- Display interface (HTN) Single display
- Measurement sampling rate times/s 3
- Analog bar sampling rate times/s 10
- Analog bar 31 bars
- True RMS
- AC voltage frequency response 45 ~ 400Hz
- AC current frequency response 45 ~ 400Hz
- Diode/Continuity test 3.5V
- Auto/Manual range
- Auto power off
- Continuity buzzer
- Low battery indication
- Data hold
- MAX/MIN
- Function selection
- Flashlight
- Auto backlight
- Operating temperature 0 °C to 40 °C
- 2m drop test
- Safety rating IP65
- General
- Power supply: 6F22 9 V battery
- Display dimensions: 66 × 51 mm
- Color: Red-gray
- Dimensions: 206.5 × 95.5 × 61 mm
- Weight: 450 g
Kit contains
- Universal meter Uni-T UT195E
- Test leads
- Batteries
- Case
- Instruction
579611
Data sheet
- Zakres pomiarowy napięcia DC
- 200mV/2000mV/20V/200V/1000 V
- Zakres pomiarowy napięcia AC
- 200V/750V
- Zakres pomiarowy natężenia DC
- 2mA/20mA/200mA/20A
- Zakres pomiarowy natężenia AC
- 2mA/20mA/200mA/20A
- Zakres pomiarowy rezystancji
- 60 MΩ
- Zakres pomiarowy pojemności
- 6nF/60nF-600uF/6mF-60mF
- Zakres pomiarowy częstotliwości
- 60 Hz - 10 MHz
- Pomiar temperatury
- Nie
- Regulacja zakresu pomiarowego
- Automatyczna
- True RMS
- Tak
- Funkcja Hold
- Tak
- Tester ciągłości obwodu
- Akustyczyny
- Tester diod
- Tak
- Pomiar hFE tranzystorów
- Nie
- Buzzer
- Tak
- Wskaźnik rozładowanej baterii
- Tak
- Automatyczny wyłącznik
- Tak
- Podświetlenie wyświetlacza
- Tak
- Battery type
- 6F22
- Length
- 206 mm
- Width
- 95 mm
- Thickness
- 61 mm
- Weight
- 450 g
Manufacturer Lechpol Electronics Leszek Spółka komandytowa Garwolińska 1 08-400 Miętne Poland sprzedaz@lechpol.pl
Responsible person Lechpol Electronics Leszek Spółka komandytowa Garwolińska 1 08-400 Miętne Poland sprzedaz@lechpol.pl
