zł2.79 tax excl.
The protection circuit for one Li-Ion cell with a voltage of 3.7 V. It has the function of charging, discharging and over-discharge protection. The cells can be discharged with a continuous current of up to 12 A
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
The BMS protection system is designed for one Li-Ion cell with a nominal voltage of 3.7 V. The module has a charging, discharging and over-discharge protection function. The cells can be discharged with a continuous current of up to 12 A. The BMS module allows for comprehensive service of Li-Ion 18650 cells without the need for dedicated chargers and additional elements.
Features
- Charging voltage: 4.25 ± 0.05V
- Discharge voltage: 2.5 ± 0.1V
- Continuous work current: 12 A
- Designed for 1 Li-Ion cell (3.7 V)
- Overload, overcurrent and short circuit protection
- Dimensions: 35 x 7 x 2 mm
Connection diagram
