LCD-AG-C128064CF-FHW K/W-E6 – 128×64 graphic LCD display
ID: 179278
5906623492336
zł32.37
Tax included
zł26.32 tax excl.
The 128×64 graphic display with black text and white ECO backlight provides an energy-efficient, compact solution for projects requiring a clear and legible interface. It is suitable for industrial, measurement, and embedded applications where small size, low power consumption, and easy installation are important.
Description
The LCD-AG-C128064CF-FHW K/W-E6 graphic display offers a resolution of 128×64 pixels using FSTN technology, with a built-in ST7565R controller and a high-contrast COG (Chip-On-Glass) matrix. It is designed for direct THT mounting on the device’s main PCB. Thanks to uniform ECO-type LED backlighting with a current consumption of 15 mA (with separate control), it ensures good readability under a wide range of lighting conditions. Powered by 3.3 V, it displays black characters on a light background, providing high contrast. All capacitors in the circuit may have the same capacitance of 1 µF, simplifying application design.
Features
- Display type: FSTN graphic LCD
- Resolution: 128×64 pixels
- Controller: ST7565R
- Technology: COG (Chip-On-Glass)
- Supply voltage: 3.3 V
- External dimensions: 68.7 × 48.5 mm
- Mounting: THT (goldpin connectors)
- Backlight: white, 1 LED, separate ECO 15 mA supply
- Character color: black on light background
- Recommended capacitor value: 1 µF
- Operating temperature: extended range
- Application: direct PCB mounting
- Compliant with RoHS directive
179278
Data sheet
- Screen type
- COG
- Diagonal (inch)
- 2,7
- Resolution
- 128 x 64 px
- Interface
- Parallel
- Touch
- No
