zł16.99 tax excl.
A compact stepper motor controller with the TMC2209 system with an operating voltage from 4.75 to 28 V. It offers smooth, quiet operation, high efficiency, various operating modes and easy configuration. It is controlled via the STEP/DIR interface and is an ideal solution for 3D printers and similar applications. BIGTREETECH TMC2209 V1.3
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
Advanced stepper motor controller based on the TMC2209 integrated circuit from Trinamic. It works with supply voltages from 4.75 V to 28 V, which allows the use of stepper motors with higher torque and higher supply voltages. It uses StealthChop2 technology, which ensures quiet and smooth operation of stepper motors, and SpreadCycle mode, enabling higher speeds and torques. It also supports StallGuard mode, which makes it easier to detect motor stops, and CoolStep mode, which allows you to automatically adjust the motor current to current needs. The module has built-in overheating protection and a heat sink that ensures proper heat dissipation. It communicates via the STEP/DIR interface. The controller is compatible with most popular 3D printer control boards, and its small dimensions make it easy to install even in limited spaces.
Features
- Integrated circuit: TMC2209 from Trinamic
- Logic part supply voltage: 3.3 V or 5 V
- Motor supply voltage: 4.75 to 28 V
- Maximum output current: up to 2 A RMS (2.8 A instantaneous)
- Operating modes: StealthChop2, SpreadCycle, CoolStep, StallGuard
- Communication interface: STEP/DIR
- Configuration via UART
- Step division: up to 1/256
- Connectors: compatible with popular sockets
- Protections: overload, overheating and short circuits
- Dimensions: 20.3 x 15.2 mm
