Mean Well HDR-60-24 – DIN rail power supply 60 W 24 V 2.5 A
search
  • Mean Well HDR-60-24 – DIN rail power supply 60 W 24 V 2.5 A
ID: 1201109
5902186328648
zł66.42
Tax included

zł54.00 tax excl.

Mean Well HDR-60-24 power supply with 60 W power and 24 V DC output designed for DIN rail mounting ensures high efficiency and reliability in industrial environments. Adapted for continuous operation in a wide range of temperatures and supply voltages.

24h
Available
Available quantity: 60

Description

Switched-mode power supply with 60 W power for mounting on a standard DIN rail TS35 / 7.5 or 15, designed for use in automation systems, control cabinets, and industrial installations. Equipped with a 24 V DC output with current up to 2.5 A with adjustable voltage and a full set of protections: short-circuit, overload, and overvoltage. It accepts input voltage in a wide range from 85 to 264 V AC or from 120 to 370 V DC. Thanks to passive cooling and low no-load power consumption (<0.3 W), the device is energy-efficient and durable. The housing in insulation class II and compliance with LPS and international safety standards ensure reliable operation in harsh conditions.

Features

  • DIN rail mounting TS35 / 7.5 or 15
  • Input voltage range: 85–264 V AC or 120–370 V DC
  • Output voltage: 24 V DC
  • Output current range: 0–2.5 A
  • Output power: 60 W
  • Output voltage tolerance: ±1%
  • Ripple: 150 mV
  • Efficiency: 90%
  • No-load power consumption: <0.3 W
  • Short-circuit, overload, overvoltage protection
  • Convection cooling (free air circulation)
  • Adjustable output voltage
  • LED indicating operation
  • Insulation class II
  • Compliance with LPS
  • Operating temperature: -30°C to +70°C
  • Compliance with standards UL-60950-1, UL-508, UL-1310, EN60950-1, EN61558-2-16
  • Dimensions: 52.5 x 90 x 54.5 mm
1201109

Data sheet

Output voltage
24V
Output current
2.5A
Power
60W
