5.83" (B) E-Ink e-Paper Display HAT 648x480 for Raspberry Pi - Waveshare 14600
ID: 573325
5906623422234
zł257.18
Tax included
zł209.09 tax excl.
Module with e-Paper display, 5.83" diagonal and 648x480 px resolution. Communication via SPI interface. Waveshare 5.83inch e-Paper HAT (B)
Description
E-Paper module with a 5.83" diagonal and a resolution of 648x480 px. It has the ability to display content with a two-level gray scale in three colors: red, black and white. The built-in controller communicates via the SPI interface. Displays of this type are characterized by high contrast of the displayed image and they consume power only when the displayed content is changed The module is compatible with 3.3 V and 5 V systems. The kit includes an overlay that allows you to connect the display via a 40-pin connector. On the Wiki page is available support in the form of examples of use with Raspberry Pi, Jetson Nano, Arduino, STM32.
Features
- Diagonal 5.83"
- Resolution: 648x480 px
- Interface: SPI
- Spot size: 0.184 × 0.184 mm
- Display color: red, black, white
- Grayscale: 2
- Full refresh time: 20 seconds
- Refresh power: 26.4mW (typ.)
- Standby power: <0.017 mW
- Viewing angle:> 170 °
- Voltage: 3.3V to 5V
- Outline dimensions: 125.40 x 99.50 mm
- Display dimensions: 119.232 x 88.32 mm
Kit includes
- Display e-Paper 5,83 "
- e-Paper Driver HAT containing:
- E-Paper Driver HAT module
- FFC cable
- Board with two FFC connectors
- Set of brass spacers with screws
- JST PH2.0 8P cable
573325
Data sheet
- Compatible with
- Raspberry Pi 5/4/3/2/1 A/B, Zero/Zero 2 H/WH
- Screen type
- E-Ink/Epaper
- Diagonal (inch)
- 5,83
- Resolution
- 648 x 480 px
- Interface
- SPI
- Touch
- No
