Z25 PS - Plastic enclosure
ID: 1179819
5905275010912
zł23.78
Tax included
zł19.33 tax excl.
Plastic enclosure Z25
Description
Enclosures with side panels - standard material for this series is polystyrene and ABS. The colors in which they are available is a lightgray and black. Each enclosure has front and rear panel, with the possibility of exchanging for transparent colorless, red or green filters. Some of these enclosures are also available in ventilated version.
Specification
- Type: Full
- Variant: Without gasket
- Material: PS
- Color: Black
- Height: 78.0mm
- Width: 220.0mm
- Length: 220.0mm
- Weight: 475g
Included
- Case Z25 PS
- Feet: 4.0 pcs
- Screw 3/45: 4.0 pcs
1179819
Data sheet
- Colour
- Black
- Materiał
- PS
- Hermetyczna
- Nie
- Brass bushings
- Nie
- Tightness class
- brak
- Strength class
- none
- Length
- 220 mm
- Width
- 220 mm
- Height
- 78 mm
- Housing type
- Universal
- Flammability class
- none
