Plastic enclosure ZP105.105.60UJ TM ABS
ID: 1191848
zł27.32
Tax included
zł22.21 tax excl.
ZP105.105.60UJ TM ABS - Plastic enclosure ZP105.105.60, light-colored with ears and brass inserts, made of ABS.
Description
Enclosures ZP series are suitable for all equipment where it is necessary to be sealed. Mounting pads in the enclosure allow for a secure mounting of the DIN rail inside the enclosure. Versions with ABS and PC are available. The cover can be made of transparent polycarbonate. Both parts of the enclosure are fastened with captive screws.
Specification
- Type: Full
- Variant: With brass bushing
- Material: ABS
- Color: Lightgray
- Height: 60.1mm
- Width: 105.0mm
- Length: 105.0mm
Included
- Enclosure
- Bolt M3/17/10: 4.0 pcs
1191848
Data sheet
- Colour
- Jasnoszary
- Materiał
- ABS
- Hermetyczna
- Nie
- Brass bushings
- Tak
- Tightness class
- brak
- Strength class
- none
- Length
- 105 mm
- Width
- 105 mm
- Height
- 60,1 mm
- Housing type
- Universal
- Flammability class
- none
- ZP105_105_60U.pdf (188,72 kB)
- ZP105_105_60U.step (3,55 MB)
- ZP105_105_60U.dwg (3,64 MB)
- ZP105_105_60U_2000.dwg (10,37 MB)
- ZP105_105_60U_Assembly.svgz (23,14 kB)
- ZP105_105_60U_Base.svgz (42,43 kB)
- ZP105_105_60U_Cover.svgz (31,69 kB)
- ZP105_105_60U_Complete_documentation.zip (8,52 MB)
- ZP105_105_60U_Mounting_board_ZMB105_105.pdf (78,81 kB)
- ZP105_105_60U_Mounting_board_ZMB105_105.stp (153,08 kB)
- ZP105_105_60U_Mounting_board_ZMB105_105.dwg (980,79 kB)
- ZP105_105_60U_Mounting_board_ZMB105_105_2000.dwg (2,29 MB)
- ZP105_105_60U_Mounting_board_ZMB105_105.svgz (27,44 kB)
- ZP105_105_60U_img.zip (2,31 MB)
Manufacturer Kradex Sp. z o.o. ul. Minerska 4 04-506 Warszawa Poland kradex@kradex.com.pl
Responsible person Kradex Sp. z o.o. ul. Minerska 4 04-506 Warszawa Poland kradex@kradex.com.pl
