Stacked pin header 2x20 pin, 2.54 mm pitch
ID: 42483
5902186314696
zł1.89
Tax included
zł1.54 tax excl.
The ZL2019-20 pin header with 40 pins in a stacked layout facilitates the construction of modular electronic systems using the standard 2.54 mm pitch. Designed for through-hole mounting in prototyping projects and extension boards.
Description
The ZL2019-20 pin header with a dual row of 20 pins is designed for mounting on prototyping boards, modules, and adapters compatible with the standard 2.54 mm pitch. The stacked design enables easy connection of multiple boards in a stack, allowing the construction of complex electronic systems in development platforms, microcontrollers, and hobby projects. The total length of 19.4 mm provides sufficient space for plugging and soldering connectors.
Specifications
- Type: stacked pin header
- Number of pins: 2×20
- Pitch: 2.54 mm
- Total length: 19.4 mm
- Mounting: through-hole (THT)
42483
Data sheet
- Rodzaj goldpinu
- Listwa prosta
- Rodzaj złącza
- Męskie
- Pitch
- 2,54 mm
- Liczba rzędów
- 1
- Liczba pinów
- 20
- Colour
- Black
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
