zł145.39 tax excl.
HMI module with a color LCD TFT 4.3" display with a resolution of 480x272 pixels. Equipped with a capacitive touch panel. Communication via UART interface. Accessories included. DWIN DMG48270C043_05WTC-SET
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
HMI module (Human-Machine Interface) with a color LCD TFT 4.3" display with a resolution of 480x272 px. It is equipped with a capacitive touch panel that provides interaction between the user and the system. The panel has a built-in T5L0 running on a commercial DGUS II system, a microSD card slot , buzzer and Flash memory The module communicates with an external controller via the UART interface It is powered with a voltage of 5 V and can consume a current of up to 210 mA. on production lines.
The kit includes a set of accessories, including a USB cable, SD card, FCC tape and connector, and HDL662B module for programming and debugging.
Features
- TFT LCD display
- Screen diagonal: 4.3"
- Resolution: 480x272 px
- Colors: RGB
- Touch panel type: capacitive
- Communication: UART TTL
- Built-in 8 MB Flash memory
- Brightness adjustment
- MicroSD card slot
- Buzzer
- FCC 1.0mm 10-pin UI connector
- Power supply: 5V
- Current consumption: 210 mA
- Dimensions: 106.5 x 68.3 mm
Kit contains
- HMI module DMG48270C043
- HDL662B module
- HDLUSB cable
- SD card
- FFC tape
- FFC connector
