Adapter for IDC connector - Explore D
ID: 560118
5906623411351
zł26.22
Tax included
zł21.32 tax excl.
Adapter enabling easy and quick connection of Modular DuoNect expansion modules with a ribbon cable with an IDC connector. MOD-83
Description
The adapter enables easy and quick connection of Modulowo® DuoNect ™ compatible expansion modules using a ribbon cable with an IDC connector. The set can be used for design and educational purposes, to learn programming and to enable rapid construction of prototypes and new projects.
Modulowo® DuoNect ™ solution
The Modulowo® DuoNect ™ solution enables fast and easy connection of expansion modules to Arduino , Raspberry Pi , Intel® Edison , STM32 Nucleo , Atmel Xplained , TI LaunchPad, Freescale Freedom and other platforms.
properties
- 1 place for extension modules
- Compliance with Modulowo® DuoNect ™
- Outputs for IDC 16-pin or 20-pin connector, with 2.54 mm pitch
- Output to the ARK power connector for the VIN line with 2.54 mm or 5.08 mm pitch
- Configuration jumpers for voltage selection
- Dimensions: ~ 42 mm x 35 mm
- Compliance
Included
- Printed circuit MOD-83
- A set of connectors for self-assembly
To download
560118
Data sheet
- Rodzaj złącza
- Męskie/Żeńskie
- Number of pins
- Other
- Angled/straight
- N/A
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
