Pico-LCD-0.96 - module with IPS LCD display 0.96" 160x80 for Raspberry Pi Pico
ID: 586282
5906623422531
zł35.99
Tax included
zł29.26 tax excl.
Module with LCD IPS display, 0.96" diagonal and 160x80 px resolution. Communication via SPI interface. Waveshare Pico-LCD-0.96
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
The module with a color LCD IPS display with a diagonal of 0.96" and a resolution of 160x80 px, designed to work with the Raspberry Pi Pico. It has a built-in ST7735S controller, which communicates via the SPI interface. It can display the content in a full range of 65K colors, and the board has 2 buttons and a joystick at the user's disposal The module is compatible with 3.3V and 5V systems. Full documentation with examples is available on the product Wiki page.
Pinout
Features
- Display type: LCD IPS
- Diagonal 0.96"
- Resolution: 160x80 px
- Interface: SPI
- Spot size: 0.1356 x 0.135 mm
- Display color: RGB 65K
- Wide viewing angle
- ST7735S controller
- Voltage: 2.6 V to 5.5 V
- PCB dimensions: 52 x 25 mm
- Display dimensions: 21.7 x 10.8 mm
586282
Data sheet
- Screen type
- IPS
- Diagonal (inch)
- 0,96
- Resolution
- 160 x 80 px
- Interface
- SPI
- Touch
- No
