PoE HAT (F) - Power over Ethernet expansion module for Raspberry Pi 5
ID: 1189006
5906623469673
zł96.79
Tax included
zł78.69 tax excl.
PoE power module designed for Raspberry Pi 5. It allows you to use the PoE interface to power the Raspberry Pi via an Ethernet cable, eliminating the need to use a separate power supply. Waveshare PoE HAT (F)
Description
PoE power module dedicated to Raspberry Pi 5 minicomputers. It allows you to use the Power over Ethernet interface to power the Raspberry Pi via an Ethernet cable, eliminating the need to use a separate power supply. The module complies with the IEEE 802.3af/at standard and supplies 5 V and 12 V voltage to power the minicomputer and additional accessories. It uses a fully isolated switch mode power supply (SMPS) and an active cooling fan with a metal heat sink for better heat dissipation. It enables applications in the design and development of embedded systems, communications and networks, and IoT (Internet of Things).
Features
- Compatible with Raspberry Pi 5
- Standard: IEEE 802.3af/at
- Input: IEEE 802.3af/at PoE compliant
- Isolated Switching Power Supply (SMPS)
- Input voltage: 37 to 57 V DC
- Output parameters: 5 V (4.5 A), 12 V (2 A)
- Cooling: fan
- Dimensions: 70 x 56.5 mm
Kit contains
- PoE HAT module (F)
- Radiator
- Thermally conductive tapes
1189006
