Motoron M3S550 Triple Motor Controller Shield - 3-channel DC motor controller for Arduino (for assembly)
ID: 1185706
5902186316935
zł132.34
Tax included
zł107.59 tax excl.
DC motor controller that allows the movement of three drives to be controlled via an I2C interface. A board with connectors for mounting is included. Pololu 5069
Description
DC motor driver dedicated to Arduino boards. It allows you to control the movement of three drives using the I2C interface. It can work with motors with a supply voltage from 1.8 to 22 V and has a capacity of up to 1.7 A per motor (continuous operation). The controller has a built-in protection in the event of loss of communication with Arduino and the ability to configure the response if an error occurs. The user can set the maximum acceleration and the starting speed of the motor, and the shield construction allows you to connect the drivers with each other. The manufacturer's website includes a user manual and a library with sample programs.
Features
- Operating voltage range: 1.8 V to 22 V
- Maximum output current per motor: 1.7 A continuous, 5 A instantaneous
- Voltage range of the logic part: 2.8 V to 5.5 V
- Control interface: I2C
- I2C clock frequency: up to 400 kHz
- CRC control capability
- Configurable motion parameters:
- Maximum acceleration/deceleration
- Initial speed
- Delay for change of direction
- PWM frequency: eight options available from 1 kHz to 80 kHz
- Protection in case of communication loss
- Configurable automatic error response
- Measurement of motor supply voltage (VIN)
- Possibility to power the Arduino directly or via an external stabiliser (not supplied)
- Two status LEDs
- Motor direction LEDs
Kit contains
- Motoron M3S550 Triple Motor Controller Shield
- Connector 1x10 straight female
- Connector 1x8 straight female
- 4 x 2pin 3.5 mm screw connector
- 4 x 2pin 5 mm screw connector
- Connector 1x25 straight male
1185706
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
