Finder 66.82.9.024.4000 Power Relay 2P 30A DC 24V
ID: 1199715
5902186306974
zł47.59
Tax included
zł38.69 tax excl.
The Finder 66.82.9.024.4000 is a 2P power relay rated at 30 A with a 24 V DC coil and Faston 250 connectors. Designed for panel mounting in applications requiring reliable switching of high electrical loads.
Description
The Finder 66.82.9.024.4000 power relay is designed for industrial and automation applications, featuring two changeover contacts rated up to 30 A. The coil operates at 24 V DC within a voltage range of 19.2 to 26.4 V. The housing supports panel mounting via Faston 250 terminals. The relay uses AgSnO₂ contact material for increased durability and reliability under high loads. It provides 6 kV isolation between coil and contacts, offers long electrical life (100,000 cycles), and is rated for operation in a wide temperature range.
Specifications
- contact configuration: 2 × changeover (2P)
- coil voltage: 24 V DC
- coil operating range: 19.2–26.4 V
- coil resistance: 340 Ω
- current consumption: 70.5 mA
- coil power: 1.7 W
- holding voltage: 12 V
- release voltage: 2.4 V
- coil-to-contact isolation: 6 kV
- contact current rating: 30 A (resistive load)
- contact material: AgSnO₂
- mounting type: panel mount, Faston 250 terminals
- electrical life: 100,000 cycles
- operating temperature: −40 °C to +70 °C
- dimensions: 33.5 × 31 × 68.5 mm
1199715
Data sheet
- Output current
- 30 A
- Number of channels
- 2
- Executive element
- Przekaźnik elektromagnetyczny
- Coil voltage
- 24 VDC
Manufacturer FINDER POLSKA SPÓŁKA Z OGRANICZONA ODPOWIEDZIALNOŚCIĄ Logistyczna 27, Sady 62-080 Tarnowo Podgórne Poland finder.pl@findernet.com
Responsible person FINDER POLSKA SPÓŁKA Z OGRANICZONA ODPOWIEDZIALNOŚCIĄ Logistyczna 27, Sady 62-080 Tarnowo Podgórne Poland formularz kontaktowy na stronie osoby odpowiedzialnej
