Safety relay 24V 6A Finder 7S.14.9.024.4220
ID: 1195576
8012823420400
zł355.14
Tax included
zł288.73 tax excl.
Finder 7S.14.9.024.4220 is a modular safety relay equipped with two normally open (NO) contacts and two normally closed (NC) contacts, each with a 6 A load capacity at 250 V AC. The relay is powered by a 24 V DC coil voltage and is designed for DIN rail mounting, facilitating easy integration into industrial automation systems.
Description
Finder 7S.14.9.024.4220 is a modular safety relay designed for industrial automation systems. It is equipped with two normally open (NO) contacts and two normally closed (NC) contacts, each with a 6 A load capacity at 250 V AC. Powered by 24 V DC, it is suitable for DIN rail mounting, making installation and integration into control systems easier. Finder 7S.14.9.024.4220 is a robust and reliable solution for applications requiring a high level of safety, ensuring stable operation and long service life in demanding industrial environments.
Specifications
- Number of outputs: 4
- Contact configuration: 2 x NO, 2 x NC
- Mounting: DIN rail
- Manufacturer series: 7S
- Operating temperature: -40...70°C
- Electrical connections: Spring-loaded terminals
- Safety category: 3
- IP rating: IP20
- Housing dimensions: 22.5 x 86.2 x 100.3 mm
- Insulation voltage: 250 V
- Contact rating: 6 A / 250 V AC
- Switching capacity: 1.5 kVA
- Mechanical durability: 10,000,000 cycles
- Electrical lifespan: 100,000 cycles
1195576
Data sheet
- Output current
- 6A
- Number of channels
- 4
- Executive element
- Security module
- Coil voltage
- 24 VDC
Manufacturer
- FINDER POLSKA SPÓŁKA Z OGRANICZONA ODPOWIEDZIALNOŚCIĄ
- Logistyczna 27, Sady
- 62-080 Tarnowo Podgórne
- Poland
- [email protected]
Responsible person
- FINDER POLSKA SPÓŁKA Z OGRANICZONA ODPOWIEDZIALNOŚCIĄ
- Logistyczna 27, Sady
- 62-080 Tarnowo Podgórne
- Poland
- formularz kontaktowy na stronie osoby odpowiedzialnej
