ID: 1192894
5902186326248

Advanced function generator with a maximum output frequency of 60 MHz and two output channels. With a sampling rate of 150 MSa/s, 16kpts memory and 14-bit vertical resolution, the device provides high precision and reliability. Equipped with USB and LAN interfaces, it allows easy integration with measurement systems and task automation. Siglent SDG1062X

Retired

Description

The SIGLENT SDG1062X Function Generator is an advanced device for generating function and arbitrary waveforms, ideal for engineers, scientists, and electronics enthusiasts. It offers a maximum output frequency of 60 MHz and supports dual output channels, allowing simultaneous generation of high-precision signals. With a sampling rate of 150 MSa/s and a vertical resolution of 14 bits, the device ensures excellent signal quality, meeting the requirements of even the most demanding applications. Its 16kpts memory enables storage of complex waveforms, while a frequency resolution of 1 μHz provides exceptional precision. The device features EasyPulse technology to eliminate jitter in pulse signals and TrueArb for enhanced fidelity of arbitrary waveforms.

With multiple modulation modes, including AM, FM, PM, PWM, ASK, PSK, and FSK, the generator is suitable for a wide range of applications, from testing electronic circuits to developing communication systems. Standard interfaces like USB Host, USB Device (USBTMC), and LAN (VXI-11) enable easy connection to computers and other devices, while an optional GPIB interface allows integration into advanced measurement systems. The clear 4.3” TFT-LCD display ensures intuitive function management and easy viewing of settings. Combined with its compact design, the SDG1062X is the perfect choice for users who value performance and reliability. Additional features like Sweep, Burst, and Harmonic Generator functions make it a versatile tool for any R&D lab.

Features

  • Maximum output frequency: 60 MHz
  • Number of output channels: 2
  • Sampling rate: 150 MSa/s
  • Memory depth: 16kpts
  • Frequency resolution: 1 μHz
  • Vertical resolution: 14 bits
  • Standard interfaces: USB Host, USB Device (USBTMC), LAN (VXI-11)
  • Display: 4.3" TFT-LCD
  • Modulation types: AM, FM, PM, PWM, ASK, PSK, FSK
  • Additional features: EasyPulse, TrueArb, Sweep, Burst, Harmonic Generator
  • Dimensions: 260 x 107 x 296 mm

Kit contains

  • Siglent SDG1062X
  • Power cable
  • Calibration certificate
  • USB cable
