Development board equipped with STM32F411RE microcontroller (512 KB Flash, Cortex-M4). Dedicated to running MicroPython scripts. Adafruit 5417

4 weeks
On request
Kamami is the official distributor of Adafruit modules and development kits. All boards of this brand in our offer are original and come directly from the manufacturer.

Description

Development board equipped with the STM32F411RE microcontroller (512 kB Flash, Cortex-M4), dedicated to running MicroPython scripts. It offers a microSD card slot, a microUSB connector, 4 LEDs, and a reset and user button. There are 24 GPIO pins on the board. The microcontroller has a built-in DFU bootloader that allows easy firmware update.

MicroPython is a variant of Python (version 3.4) suited to run on a microcontroller. It comes with lots of optimizations so it runs efficiently and uses very little RAM. MicroPython runs in bare-metal mode. The built-in pyb module contains functions and classes to control peripheral devices available on the board, such as UART, I2C, SPI, ADC and DAC.

The board can be inspected with:

  • REPL - By connecting to a computer via USB, the disc appears as a virtual USB communication port (CDC VCP) and can use any serial terminal to connect and get a Python REPL prompt. This allows you to type and execute Python commands immediately, just as you would when running Python on your computer.
  • Remote script - you can change REPL mode to raw REPL mode by sending ctrl-A and then in raw REPL mode send any Python script for immediate execution.
  • From the file- pyboard has a small, built-in filesystem which is located in the flash part of the microcontroller. It also has an SD card slot. Pyboard appears as a USB flash drive and you can access (mount) the internal file system and SD card this way. A python script named main.py will be executed by the board on startup. This way you can run scripts without being connected to the computer.

Features

  • STM32F411RE microcontroller
  • 96 MHz Cortex M4 with FPU
  • 512 kB flash ROM and 128 kB RAM
  • Micro USB connector for power and serial communication
  • Micro SD card slot
  • 24 GPIO
  • 12-bit analog-to-digital converter
  • 4 LEDs (red, green, yellow and blue)
  • 1 reset and 1 user button
  • Built-in 3.3V LDO voltage stabilizer, up to 250mA, input voltage range from 3.6V to 16V
  • DFU bootloader in ROM for easy firmware update
