ID: 585045
zł4.90
Tax included

zł3.98 tax excl.

Right-angle USB Type-A connector designed for through-hole THT mounting on PCBs, featuring a black insulator and four signal contacts. CZT USBS1ARB-V

24h
Available
Available quantity: 20

Description

The USBS1ARB-V is intended for implementing a USB Type-A interface in electronic devices that require through-hole mounting on printed circuit boards. The right-angle design allows the USB port to be oriented parallel to the PCB surface, facilitating enclosure integration and reducing overall assembly height.

The connector is manufactured using THT technology and is equipped with four signal contacts compliant with the USB Type-A standard. The housing with a black insulator and a metal shielding shell ensures stable fixation on the PCB and mechanical durability during repeated USB plug insertion and removal.

The product is suitable for use in consumer electronics, communication modules, control devices, and embedded systems where a reliable USB connector mounted directly on the PCB is required.

Features

  • Connector type: Standard USB receptacle
  • Interface type: USB Type-A
  • Number of ports: 1
  • Number of contacts: 4
  • Mounting type: THT
  • Orientation: Right-angle
  • Mounting position: Vertical
  • Insulator color: Black
  • Housing material: Metal shield
  • Installation method: Soldering into printed circuit board
