Adafruit Switchable USB Type A to C Breakout Board
ID: 1192390
5902186300330
zł30.60
Tax included
zł24.88 tax excl.
The Adafruit Switchable USB Type A to C Breakout Board is a versatile tool for electronics and microcontroller developers that lets them manually manage USB lines. It lets you create secure "charge-only" connections, monitor voltages, and analyze signals without compromising the integrity of your connections. Its compact size and easy access to the signal lines make it ideal for R&D, labs, and prototyping. Adafruit 4909
Description
The Adafruit Switchable USB Type A to C Breakout Board allows you to manually switch the signal and power lines on your USB cable. Using a four-position DIP switch, you can independently turn on or off each of the lines: VBUS (power), GND (ground), D+, and D- (data lines). The board is designed for low-voltage, low-current applications, such as microcontroller projects. Disabling the data lines provides a "charge-only" function, while disconnecting the power allows you to monitor high- or low-side currents. All lines are routed to labeled pads, allowing you to easily connect test probes and analyze signals or voltages. The C&K SDA04H1SBD switches used on the board are rated at 5V and 100mA.
Features
- Connector type: USB Type A (male) to USB Type C (female)
- Four independent DIP switches for VBUS, GND, D+, D-
- Possibility to disconnect data lines to obtain charging function without data transmission
- Easy monitoring of voltages and signals thanks to the led-out measuring pads
- Recommended for low-current applications (max. 100 mA)
- Dimensions: 39.7 × 19.0 × 9.5 mm
- Weight: 4.9 g
