LED strip with addressable RGB WS2815 diodes on a white PCB. It is powered by 12 V DC, has a length of 5 m and 30 LEDs/m. Protection level IP30

4 weeks
Awaiting delivery

Description

LED strip with addressable RGB WS2815 diodes placed on a flexible white PCB strip. It is powered by 12 V, has 30 LEDs/m and requires up to 9 W/m to work at full capacity. The tape offers an IP30 protection level which means it is not waterproof. It is dedicated mainly to installations inside buildings, not exposed to contact with water.

The type of WS2815 used is addressed LEDs with a built-in driver, which means that each LED can be controlled individually. They have a convenient control interface that requires only one data line, thanks to which we are able to control a large number of elements without taking up many microcontroller outputs.

WS2815 diodes support the system of resuming operation after a line interruption - in the event of failure of one diode, the other diodes will continue to glow. This system works until there are two faulty diodes next to each other.

The strip has been designed so that it can be cut and combined with other installations. Each LED can be cut off and connected to a different lighting element, maintaining its structure and full functionality.

The LED strip is equipped with a tape that allows for easy installation on flat surfaces. It will be used in lighting installations, as a decorative element in the living room, kitchen or workshop.

Features

  • Color: RGB
  • LED type: WS2815
  • Built-in driver
  • Wake Up System
  • Possibility to connect in rows
  • Refresh rate: 2kHz
  • LED density: 30 LEDs/m
  • Length: 5 m
  • Protection level: IP30
  • Strap width: 10 mm
  • Each diode can be cut off
  • Double-sided mounting tape
  • Power supply: 12V DC
  • Power consumption: 9 W/m
1179150

Data sheet

Zagęszczenie diod
30 LED/m
Wodoodporność
Nie
Sterownik
WS2815
Colour
RGB
Length
5 m
