Saleae Logic Pro 16 BLACK

Saleae Logic Pro 16 BLACK - USB Logic Analyzer

Description

Do you need big logic analysis in a small package? That’s exactly what the Logic Pro 16 brings you. The Logic Pro 16 is a 16-channel USB logic analyzer with so much style it’ll make your cell phone jealous. Simply connect it to your computer with the included USB 3.0 cable, attach your test probes and install the Saleae Logic software and you’ll be debugging in no time. Along with adding 4 more channels of signal capture, the Logic Pro 16 differs from the Logic 4 by increasing the max sample rate, and adding support for 1.8V logic levels.

The Logic Pro 16 has a rugged, custom-machined aluminum enclosure and can be carried in the included zip-up carrying case (which is small enough to toss in your laptop bag). This is a great field diagnostic tool as well as a welcome addition to any workbench.

Features

• 16 Multi-Use Inputs - Analog/Digital/Both
• Digital Sample Rate: 500 MS/s (Max)
• Analog Sample Rate: 50 MS/s (Max)
• Fastest Digital Signal: 100 MHz
• Supported Logic Levels (Digital): 1.2V-5.5V
• Input Voltage Range (Analog): -10V-10V
• Bandwidth (Analog): 5MHz
• Number of bits (Analog): 12 bits
• Works with RS-232, 422/3 Directly
• USB 3.0

Includes

• 1x Logic Pro 16
• 1x USB A to USB 3.0 Cable
• 32x Wire
• 32x Micro Hook Clips
• 1x Custom Carrying Case

Dimensions

• 3.6" x 3.6" x .59" ( 92 x 92 x 15 mm )

Documents

• User's Guide
• Software Download
• Product page
