Portable oscilloscope for automotive applications with a 10.1" LCD display and touchscreen. It offers four measurement channels and features good measurement performance: a bandwidth of 300 MHz, a sampling rate of 2 GSa/s and a memory buffer of 220 Mpts. Micsig ATO3004

24h
Available
Available quantity: 2
Kamami is the official distributor of Micsig oscilloscopes and accessories. All products of this brand in our offer are original and come directly from the manufacturer.


Free shipping

free shipping in Poland for all orders over 500 PLN



Same day shipping

If your payment will be credited to our account by 11:00



14 days for return

Each consumer can return the purchased goods within 14 days

Description

The Automotive Series Portable Oscilloscope from Micsig is a digital oscilloscope with a 10.1" LCD and touchscreen display and integrated automotive diagnostic software. The unit has four measurement channels and features good measurement performance: a bandwidth of 300 MHz, a sampling rate of 2 GSa/s and a memory buffer of 220 Mpts. It has numerous outputs for connection to another device via USB Host, HDMI and WiFi. In addition, the oscilloscope is equipped with a power connector and a 7500 mAh battery that allows up to 2 h of operation on a single charge. The case also has a stand that allows the oscilloscope to be placed at a 45° angle for convenient operation.


The oscilloscope is equipped with built-in, integrated software for automotive diagnostics. It supports all the necessary functions useful in the automotive sector - from analysing the operation of the charging and ignition system, through sensors, actuators or pressure tests.

Among the basic diagnostic functions we find such as:

  • Ignition test
  • Test of actuators: solenoid valves, glow plug, IAC, injectors, pressure regulator, throttle valve
  • Test of sensors: ABS, air flow, acceleration, camshaft, temperature, Lambda probe, throttle position
  • Pressure test: Intake manifold, exhaust pipe, cylinder, connecting rod
  • Charging circuit test


The device has built-in support for communication via protocols widely used in automotive: CAN, LIN, Flexray and K-line.


The oscilloscope has 32GB of built-in memory, allowing the user to store screenshots directly on the device, and the built-in quick write function makes the data recording process much easier and simpler. For the oscilloscope, the manufacturer also provides apps available for PCs and Android and iOS mobile devices. This allows you to conveniently use the device remotely. Included with the device are BNC probes, a power supply and accessories to make working with the oscilloscope easier.

Features

  • Bandwidth: 300 MHz
  • Channels: 4
  • Sampling rate: 2 GSa/s
  • Memory buffer: 220 Mpts
  • Capture rate up to 300,000 wfm/s
  • Input sensitivity range: 1mV/div ~ 10V/div (1MΩ)；1mV/div ~ 10V/div (50Ω)
  • Bandpass filter: 20MHz, Low Pass (up to 30KHz)
  • Input impedance: 1MΩ/50Ω
  • Time base: 1ns/div ~ 1ks/div
  • Outputs: Wi-Fi, HDMI, USB 3.0/2.0 Host, USB Type C, GND, DC power, trigger output
  • Test support: charging/starting circuits, sensors, actuators, ignition, networks (CAN L/H, CAN FD, LIN, Flexray, K-line), combination tests
  • Decoding of interfaces: UART, CAN, CAN FD, LIN, SPI, I²C
  • Display:
    • TFT LCD 10.1"
    • Resolution 1280 x 800 pixels
    • Display range 11x10
    • Capacitive touchscreen
  • 32 GB on-board memory, waveforms and screenshots can be viewed and edited on the oscilloscope
  • Android and iOS apps and PC for remote control
  • Battery: 7.4 V, 7500 mAh (operating time up to 2 h)
  • Dimensions: 265 x 192 x 50 mm
  • Weight: 1.9 kg

Kit contains

  • Oscilloscope
  • 2 x BNC probe
  • 4 x crocodile clips
  • 4 x BNC adapter to banana connector
  • 4 x flexible tip
  • Power supply
  • Power supply plug
1184400

Data sheet

Type of oscilloscope
Portable
Bandwidth
300 MHz
Sampling rate
2 Gsps
Memory depth
220 Mpts
Number of channels
4
