4-channel digital oscilloscope with feature set for automotive diagnostics. It offers a frequency bandwidth of 100 MHz and samples up to 1 GS/s. It can work with Windows-based computers. Hantek 6104BE

24h
Available
Available quantity: 2
Kamami is the official distributor of Hantek oscilloscopes and accessories. All products of this brand in our offer are original and come directly from the manufacturer.


Free shipping

free shipping in Poland for all orders over 500 PLN



Same day shipping

If your payment will be credited to our account by 11:00



14 days for return

Each consumer can return the purchased goods within 14 days

Description

4-channel digital oscilloscope with feature set for automotive diagnostics. It features a bandwidth of 100 MHz and a sampling rate of 1 GSa/s. It has no built-in display and requires a computer with dedicated software to work properly. It has 20 built-in measurement functions, PASS/FAIL control and more than 80 functions dedicated to automotive measurements, including charging and ignition system performance analysis, sensors, actuators and pressure tests. The device does not require an additional power supply, a single USB cable is sufficient. The oscilloscope can work with Windows 7, 8, 10 operating systems.

Features

  • Number of channels: 4
  • Bandwidth: 100 MHz
  • Functions for automotive diagnostics:
    • Intake manifold vacuum and ignition
    • Petrol exhaust control valve vacuum and ignition
    • Ignition of exhaust gases at idling
    • Ignition of exhaust gases at start-up
    • Sensors: air flow meter, camshaft, crankshaft, distributor, lambda sensor, throttle position
    • CAN, LIN analyser
    • Starter and charging circuits
  • Sampling rate: 1GSa/s
  • Memory depth: 64K
  • Time base precision:u ±50ppm
  • Time base range: 2ns/div-1000s/div (sequences 1-2-4)
  • Input impedance: 1MΩ 25pF
  • Input sensitivity: 2mV/div～10V/div
  • Vertical resolution: 8-bit
  • Vertical displacement range: 2mV ~ 10V/div @ probe x1; 20mV ~ 100V/div @ probe x10；200mV ~ 1000V/div @ probe x100; 2V ~ 10000V/div @ probe x1000
  • DC gain accuracy: ±3%
  • Bandwidth limit: 20 MHz
  • Trigger mode: Edge, Pulse, Video, Alternative
  • Trigger source: CH1,CH2,CH3,CH4
  • Signal processing functions: +,-,x,÷,FFT, Invert
  • Measurement cursors: Cross, Trace, Horizontal, Vertical
  • Automatic measurement: Vpp, Vamp, Vmax, Vmin, Vtop, Vmid, Vbase, Vavg, Vrms, Vcrms, Preshoot, Overshoot, Frequency, Period, Rise Time, Fall Time, Positive Width, Negative Width, Duty Cycle
  • USB interface
  • Dimensions: 175 x 105 x 25 mm
  • Weight: 0.9 kg
1185333

Data sheet

Type of oscilloscope
Digital
Bandwidth
100 MHz
Sampling rate
1 Gsps
Memory depth
65 kpts
Number of channels
4
