ID: 1181711
5906623421343
zł35.90
Tax included

zł29.19 tax excl.

The board features the Raspberry Pi Foundation's RP2040 microcontroller and the WizFi360 module, which provides 2.4GHz WiFi communication over 802.11 b/g/n. WIZnet WizFi360-EVB-Pico

24h
Available
Available quantity: 17
Kamami is the official distributor of WIZnet network modules for Raspberry Pi Pico. All products of this brand in our offer are original and come directly from the manufacturer.

Description

The board features the Raspberry Pi Foundation's RP2040 microcontroller and the WizFi360 module, which provides 2.4GHz WiFi communication over 802.11 b/g/n.

The RP2040 is a microcontroller equipped with two ARM Cortex M0+ cores clocked at 133 MHz, 264 kB of RAM and 30 ports with I2C, SPI, UART and USB interfaces. It has a 2MB external Flash memory connected via a QSPI interface with eXecute In Place (XIP). The chip can be programmed in C/C++ or microPython.

WizFi360 is a low-cost and low-power industrial-grade WiFi module. It complies with the IEEE802.11 b/g/n standard and supports SoftAP, Station and SoftAP+Station modes. The transmission speed of the serial port can be up to 2Mbps to meet the requirements of various applications.


Płytka zasilana jest przez złącze micro USB typu B, które jest wykorzystywane także jako interfejs do programowania pamięci Flash. Mikrokontroler może być programowany i debugowany za pomocą 3-pinowego złącza Serial Wire Debug (SWD). Za zapewnienie prawidłowego zasilania odpowiada wbudowany stabilizator LDO.


All leads of the WizFi-EVB-Pico are directly connected to the GPIO of the RP2040. The module has the same pinout as the Raspberry Pi Pico board except for GPIO4, GPIO5, GPIO6, GPIO7, GPIO20, which are connected to WizFi360 on the board. These pins enable communication through the UART interface with WizFi360 and use the Wi-Fi function.

Features

  • RP2040 microcontroller with 2 MB Flash
    • Dual-core microcontroller with ARM Cortex M0+ core up to 133MHz
    • 264kByte SRAM
    • External Quad-SPI Flash memory with eXecute In Place (XIP)
  • WizFi360-PA
    • WiFi 2.4G, 802.11 b/g/n
    • Support for Station, SoftAP, SoftAP+Station modes of operation
    • Support "Data pass-through" and "AT command data transfer" mode
    • Support for configuration via AT serial commands
    • Supports TCP Server, TCP Client, UDP operating mode
    • Support working channel configuration from 0 to 13
    • Support for auto band 20 MHz, 40 MHz
    • Support for WPA_PSK, WPA2_PSK encryption
    • Built-in unique user-configurable MAC address
    • Industrial grade (operating temperature range: -40 °C to 85 °C)
    • CE, FCC certified
  • Micro-USB B port for power and communication and Flash programming
  • 40 21x51 'DIP' 1mm pins
  • 3-pin Serial Wire Debug (SWD) ARM port
  • Built-in LDO
  • Dimensions: 75 x 21 mm
1181711

Data sheet

Microcontroller
RP2040
Flash memory
2 MB
Number of I/O
30
Ethernet
none
WiFi/BT module
Yes
Bluetooth module
No
MicroSD slot
No
Length
75 mm
Width
21 mm
USB connector type
microUSB type B
