W6100-EVB-Pico - board with RP2040 microcontroller and W6100 Ethernet chip
ID: 1184038
5906623421350
zł51.70
Tax included
zł42.03 tax excl.
Board with RP2040 microcontroller and W6100 network chip. The module is equipped with an Ethernet interface. WIZnet W6100-EVB-Pico
Description
The board features the RP2040 microcontroller designed by the Raspberry Pi Foundation. The chip has two ARM Cortex M0+ cores running at up to 133 MHz and 264 kB of RAM. The microcontroller is not equipped with flash memory, but there is a 2MB external memory on the board connected via the QSPI interface.
In addition to the RP2040 chip and flash memory, the user has a 3.3 V voltage stabiliser, Boot buttons, a microUSB connector for powering and programming the module, and GPIO outputs where paraphernalia such as 12-bit ADC inputs, PWM, I2C, SPI and UART interfaces have been derived.
The module features the W6100 chip, which communicates over an SPI interface, has an embedded TCP/IP stack and supports protocols such as TCP, UDP, IPv6, IPv4, ICMPv6, ICMPv4, IGMP, MLDv1, ARP, PPPoE. The module supports 8 independent sockets simultaneously with 32KB memory and has an internal memory of 16 kilobytes for TX/RX buffers.
The W6100-EVB-Pico pinout is directly connected to the GPIO of the RP2040. The module has the same pinout as the Raspberry Pi Pico board, but GPIO16, GPIO17, GPIO18, GPIO19, GPIO20, GPIO21 are connected to the W6100.
The platform supports the C/C++ programming language. Programs can be uploaded to memory via USB interface or via SWD connector.
Features
- RP2040 microcontroller with 2MByte Flash
- Dual-core cortex M0+ at up to 133MHz
- 264kByte multi-bank high performance SRAM
- External Quad-SPI Flash with eXecute In Place (XIP)
- High performance full-crossbar bus fabric
- 30 multi-function General Purpose IO (4 can be used for ADC)
- 1.8-3.3V IO Voltage (NOTE. Pico IO voltage is fixed at 3.3V)
- 12-bit 500ksps Analogue to Digital Converter (ADC)
- Various digital peripherals
- 2 × UART, 2 × I2C, 2 × SPI, 16 × PWM channels
- 1 × Timer with 4 alarms, 1 × Real Time Counter
- 2 × Programmable IO (PIO) blocks, 8 state machines total
- Flexible, user-programmable high-speed IO
- Can emulate interfaces such as SD Card and VGA
- Includes W6100
- Supports Hardwired Internet Protocols: TCP, UDP, IPv6, IPv4, ICMPv6, ICMPv4, IGMP, MLDv1, ARP, PPPoE
- Supports 8 independent SOCKETs simultaneously with 32KB memory
- Internal 16 Kbytes Memory for TX/ RX Buffers
- SPI Interface
- Micro-USB B port for power and data (and for reprogramming the Flash)
- 40 pin 21x51 'DIP' style 1mm thick PCB with 0.1" through-hole pins also with edge castellations
- 3-pin ARM Serial Wire Debug (SWD) port
- 10 / 100 Ethernet PHY embedded
- Supports Auto Negotiation
- Full / Half Duplex
- 10 / 100 Based
- Built-in RJ45(RB1-125BAG1A)
- Built-in LDO (LM8805SF5-33V)
1184038
Data sheet
- Microcontroller
- RP2040
- Flash memory
- 2 MB
- Number of I/O
- 30
- Ethernet
- 100Mb x1
- WiFi/BT module
- No
- Bluetooth module
- No
- MicroSD slot
- No
- Length
- 75 mm
- Width
- 21 mm
- USB connector type
- microUSB type B
