Makerbase ODrive-S - ESC controller for 56V 60A brushless motors
ID: 1187441
5906623472932
zł284.79
Tax included
zł231.54 tax excl.
An advanced speed controller designed to power three-phase brushless motors in various applications, such as driving robots, walking robots or gimbals. Supports input voltage range from 12V to 56V. Maximum constant current is 60A. Makerbase ODrive-S
Description
The Makerbase ODrive-S BLDC motor controller is an advanced speed controller designed to power three-phase brushless motors in various applications, such as robotics, walking robots, walking robots and gimbals. It supports an input voltage range from 12 V to 56 V. The maximum constant current is 60 A, which allows you to power motors with appropriate power. The controller is based on the STM32F405RGT6 microcontroller, which provides efficient and advanced control functions. It uses MOSFET transistors which are used to control the motor current. It supports various sensor types including AS5047, TLE5012B or AMT10, giving you the flexibility to choose compatible motors.
The module offers various control interfaces such as PWM (pulse width modulation), UART, STEP/DIR, USB and CAN, which facilitates integration with various types of controllers and devices. Allows you to select control modes including speed, position or torque.
The Makerbase ODrive-S controller is an advanced device that provides precise control and performance of brushless motors in a variety of electrical applications. Its advanced features and control interfaces make it an extremely useful tool in the field of electric vehicles.
Features
- Operating voltage: 12V to 56V
- Maximum current: 60 A
- Maximum instantaneous current: 120 A
- Designed for 3-phase brushless motors
- Control system: STM32F405RGT6
- Sensor type: AMT10L, AS5047, TLE5012B
- Control interface: PWM, STEP/DIR, UART, USB, CAN
- Control modes: speed, position, torque
- Dimensions: 60 x 60 mm
Kit contains
- ODrive-S V3.6
- Power cord
- Radiator
- Micro USB cable
- 3 x motor cable
- PH2.0 5-pin cable 30 cm
- PH2.0 6-pin cable 30 cm
- PH2.54 5-pin cable 30 cm
- Resistor
- Screw set
