zł229.18 tax excl.
A base board dedicated to Raspberry Pi CM4 modules. It is equipped with two RJ45 connectors, USB 2.0 and a microSD slot. In addition, there is a fan connector on the board. Waveshare CM4-DUAL-ETH-MINI-BOX (EU)
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
Mini Dual Gigabit Ethernet Base Board is a base board for Raspberry Pi CM4 modules. It is equipped with special connectors for connecting the CM4 module and the outputs of the basic interfaces, including a USB 2.0 connector, two RJ45 Ethernet and a 40-Pin GPIO connector compatible with HAT modules. The board is additionally equipped with a micro SD card slot and a fan connector.
The base board is housed in a metal enclosure providing protection from mechanical damage and proper cooling thanks to a built-in fan. Holes have been cut in the case to ensure free access to the basic connectors and sockets on the board. Access to the 40-pin connector is guaranteed by a cover with magnets. Full documentation is available on the product Wiki page.
Features
- CM4 connector: suitable for all variants of the Raspberry Pi CM4 module (not included)
- Standard 40-pin Raspberry Pi HAT connector
- 2 x Gigabit Ethernet connector
- 1 x USB 2.0 connector
- USB Type-C connector
- Micro SD card connector for RPI CM4 Lite modules
- 5V fan controller
- Metal case
- 5V power supply
- Dimensions: 59.5 x 75 x 26 mm
Kit contains
- CM4-DUAL-ETH-MINI in a metal case
- EU power supply 5V 3A
- Screwdriver
- Thermally conductive tape
- Anti-slip feet
